Bently Nevada 3300 NSv Metric Probe with Extended Unthreaded Length

Complete Suffix Breakdown: 330904-05-14-05-02-00

• 330904 = 3300 NSv Probe, M8X1 thread, with armor
• -05 = Unthreaded Length: 50 mm
• -14 = Overall Case Length: 140 mm
• -05 = Total Cable Length: 0.5 meter (20 inches)
• -02 = Miniature coaxial ClickLoc connector, standard cable
• -00 = Agency Approval: Not required

Core Technical Specifications

• Measurement Performance
• Brand: Bently Nevada
• Model: 3300 NSv Proximity Probe
• Linear Range: 1.5 mm (60 mils) from 0.25 mm to 1.75 mm target gap.
• Incremental Scale Factor: 7.87 V/mm (200 mV/mil) with interchangeability tolerance.
• Frequency Response: 0 to 10 kHz, plus 0 to minus 3 dB typical.
• Deviation from Linear: Less than plus or minus 0.06 mm (plus or minus 2.3 mils).
• Probe DC Resistance: 4.0 plus or minus 0.5 ohms for 0.5m length.

• Physical Characteristics
• Thread Type: Metric M8X1 with stainless steel armor.
• Unthreaded Length: 50 mm for installation flexibility.
• Overall Case Length: 140 mm.
• Probe Tip: Polyphenylene Sulfide (PPS) for chemical resistance.
• Case Material: AISI 304 Stainless Steel.
• Cable: 75 Ohm coaxial, FEP insulated, 0.5 meter total.
• Minimum Bend Radius: 25.4 mm (1.0 inch) even with armor.
• Environmental Tolerance
• Operating Temperature: Minus 52°C to plus 177°C (minus 62°F to plus 351°F).
• Storage Temperature: Minus 52°C to plus 177°C (minus 62°F to plus 351°F).
• Pressure Seal: Viton O-ring prevents differential pressure leaks.
• Temperature Classifications: Meets EPL Ga, Gc, and Dc requirements.

Frequently Asked Questions

• Q: What does the -05 unthreaded length option mean?
• A: This 330904-05-14-05-02-00 includes 50 mm of smooth shaft before threads begin.
• Q: Can I use this probe with my existing Bently Nevada monitor?
• A: Yes. This 3300 NSv probe is compatible with all 3300 XL NSv Proximitor Sensors.
• Q: What is the correct gap setting for this probe?
• A: Bently Nevada recommends a 1.0 mm (40 mils) initial gap.
• Q: Does this probe require an extension cable?
• A: No. The 0.5m integrated cable connects directly to the Proximitor.
• Q: What is the benefit of the 50 mm unthreaded section?
• A: It provides greater flexibility for probe mounting in tight spaces.
