Bently Nevada 3300 NSv Proximity Probe – Precision Vibration Monitoring

Complete ordering information – tree structure

• Brand: Bently Nevada
• Model: 330910-05-11-10-02-00 (3300 NSv Proximity Probe, M10x1 thread, with armour)
  • -05 : 50 mm unthreaded length
  • -11 : 110 mm overall case length
  • -10 : 1.0 metre (39 inch) total length
  • -02 : miniature coaxial ClickLoc connector, standard cable
  • -00 : no agency approval required

Core technical specifications

• Brand: Bently Nevada
• Model: 330910-05-11-10-02-00
• Linear range: 1.5 mm (60 mils) – begins 0.25 mm from target
• Incremental scale factor (ISF): 7.87 V/mm (200 mV/mil) ±12.5%/-20%
• Deviation from straight line (DSL): less than ±0.06 mm (±2.3 mils)
• Frequency response: 0‑10 kHz, +0/-3 dB typical (305m field wiring)
• Recommended gap: 1.0 mm (40 mils) – output -1 to -13 Vdc
• Target size (min): 8.9 mm dia / recommended 13 mm dia
• Probe DC resistance (1m): 4.2 ±0.5 Ω (center to outer)
• Extension cable data: center 0.220 Ω/m, shield 0.066 Ω/m, capacitance 69.9 pF/m
• Field wiring: 0.2‑1.5 mm² (16‑24 AWG), max 305 m to proximitor
• Temperature range: operating/storage -52°C to +177°C (-62°F to +351°F)
• Pressure sealing: Viton O‑ring – differential pressure design

Frequently asked questions

• Can I use this 3300 NSv Proximity Probe with my old 3300 RAM system? Yes – the NSv version is mechanically and electrically interchangeable with previous 3300 RAM probes.
• What is the maximum field wiring length to the monitor? You can run up to 305 metres (1000 feet) of triad cable between the proximitor and the monitor.
• Does the probe withstand aggressive process media? Yes – the PPS tip and FEP cable offer increased chemical resistance, ideal for process compressors.
• What torque should I apply when mounting into a machine case? Use only finger‑tight (max 0.56 N·m) – higher torque can damage the probe tip.
• How does the armour affect bending? Even with stainless steel armour, you can safely bend to a 25.4 mm radius.
