Specifications

Inputs

• Transducer Signals: Accepts from 1 to 6 RTD or TC transducer signals.
• Input Impedance: 10 MΩ for each lead input.

Power Consumption

• 3500/60: Nominal consumption of 7 watts.
• 3500/61: Nominal consumption of 9 watts.

Transducers

• TCs Type E: -100 °C to +1000 °C (-148 °F to +1832 °F).

Physical Dimensions and Weight

Monitor Module

• Dimensions: 241.3 mm x 24.4 mm x 241.8 mm (9.50 in x 0.96 in x 9.52 in)
• Weight: 0.91 kg (2.0 lb)

I/O Modules

• Standard I/O Module Dimensions: 241.3 mm x 24.4 mm x 99.1 mm (9.50 in x 0.96 in x 3.90 in)

• Standard I/O Module Weight: 0.45 kg (1.0 lb)

• I/O Modules with Internal Barrier Dimensions: 241.3 mm x 24.4 mm x 163.1 mm (9.50 in x 0.96 in x 6.42 in)

• I/O Modules with Internal Barrier Weight: 0.46 kg (1.01 lb)

Rack Space Requirements

• Monitor Module: Requires 1 full-height front slot.
• I/O Modules: Requires 1 full-height rear slot.

These detailed specifications ensure proper selection and installation of the 3500 system components, catering to various industrial monitoring and control applications.
