Bently Nevada 3300 5mm Armored Proximity Probe

Product Identification & Configuration

Manufacturer: Bently Nevada
Base Model: 3300 Series 5mm Proximity Probe
Full Part Number: 330174-00-06-10-02-00
330174: 5mm Probe, M8x1 thread, with armor
-00: Unthreaded Length = 0 mm
-06: Overall Case Length = 60 mm
-10: Total Cable Length = 1.0 metre (3.3 feet)
-02: Connector = Miniature coaxial ClickLoc™
-00: Agency Approval = Not required

Key Electrical & Physical Specifications

Power Supply: Requires -17.5 Vdc to -26 Vdc at 12 mA max.
Output Impedance: 50 Ω for standard system integration.
Probe Resistance (1.0m): 7.59 Ω ± 0.50 (center to outer conductor).
Probe Tip: Made of durable Polyphenylene sulfide (PPS).
Probe Case: Constructed from AISI 304 stainless steel with armor.
Operating Temperature: -35°C to +177°C (-31°F to +351°F).
Magnetic Immunity: Low sensitivity to 60 Hz fields up to 300 Gauss.

Mechanical Installation Details

Mounting Thread: M8 x 1.0 metric thread standard.
Max Thread Engagement: Limit engagement to 12 mm depth.
Installation Torque: Tighten to 5.1 N·m (45 in·lb) recommended.
Maximum Torque: Absolute maximum is 7.3 N·m (65 in·lb).
Connector Torque: Maximum 0.565 N·m for connector mating.
Minimum Bend Radius: Maintain 25.4 mm (1.0 in) for cable.
Tensile Strength: 222 N (50 lbf) rating on case and cable.

Common Questions (FAQ)

What is the main difference from standard probes? This 330174-00-06-10-02-00 model includes protective armor.
What target material is used for specs? Specifications reference an AISI 4140 steel target.
What is the standard test gap? Performance data assumes a 1.27 mm (50 mil) gap.
Is it suitable for hazardous areas? No, the "-00" suffix indicates no hazardous location approval.
