Overview

Engineers choose the RESR20USA229 optical encoder ring for precision motion control applications across modern industrial manufacturing environments.

Technical Specifications

• The manufacturing brand name represents Renishaw engineering excellence across global industrial automation markets.
  • The specific engineering product model designation clearly identifies the advanced RESR20USA229 optical encoder ring.
  • The measurement range provides sizing options from 52 millimeters to 550 millimeters diameter.
  • The system resolution features precise 20 micrometer pitch graduations marked directly on surfaces.
  • The frequency response supports high operating speeds up to 500 kHz maximum capacity.
  • The structural linearity utilizes high precision taper mount systems to reduce radial runout.
  • The optical sensitivity provides optimal signal detection capability during fast machine tool operations.
  • The operating temperature range spans from minus 10 degrees to 70 degrees Celsius.
  • The environmental tolerance provides high immunity against dust particles and light machining oils.
  • The interference immunity prevents shaft wind-up errors through an advanced non-contact format.

Installation Guide

• Technicians mount the scale ring securely onto heavy machine shafts using specialized mechanical taper systems.
  • Step one always involves cleaning mounting surfaces thoroughly before the core mechanical assembly process begins.
  • Step two specifically requires aligning the ring carefully to reduce any eccentricity and radial runout.
  • Step three carefully secures the mounting bolts evenly while following strict manufacturer torque guidelines.

Package Contents and Shipping

• Valued buyers receive all essential hardware components inside safe industrial packaging materials without any delay.
  • The standard shipping package includes one stainless steel scale ring unit for immediate system installation.
  • Each standard shipment includes multiple specialized mounting hardware components for secure mechanical integration.
  • Logistics partners deliver these industrial packages safely using dependable Fedex, UPS, or DHL services worldwide.

Frequently Asked Questions

• Experienced system operators frequently ask important operational questions regarding this advanced optical encoder measurement system.
  • Question: Does this innovative optical design completely eliminate mechanical backlash errors during active machine operation?
  • Answer: Yes, the advanced optical format removes mechanical backlash and structural shaft errors completely now.
