CC-PAIH51 51410069-276 Analog Input Module
16-channel universal input module with 16-bit resolution for precision process monitoring. New factory-sealed with 12-month warranty.
Technical Specifications
Brand: Honeywell
Part Number: CC-PAIH51 51410069-276
Channels: 16 single-ended
Resolution: 16-bit
Accuracy: ±0.1% FS
Sampling Rate: 250 S/s
Input Impedance: >1MΩ (voltage), 250Ω (current)
Power: 24VDC (18-32VDC)
Operating Temp: 0-60°C
Dimensions: 63.5 x 124.46 x 307.34 mm
Weight: 300g
Isolation: Channel-to-channel 500V AC
Signal Compatibility
-
Voltage:
- 0-10V
- 0-5V
- ±10V
- ±5V
-
Current:
- 0-20mA
- 4-20mA
-
RTD:
- Pt100
- Pt1000
-
Thermocouples:
- J, K, T, E, R, S, B, N
Comparison with Similar Modules
| Feature | CC-PAIH51 | CC-PDIH01 | CC-PAIH01 |
|---|---|---|---|
| Input Type | Universal Analog | Digital | Analog |
| Channels | 16 | 32 | 16 |
| Resolution | 16-bit | 1-bit | 12-bit |
| Sampling Rate | 250 S/s | N/A | 50 S/s |
| Signal Types | TC, RTD, V, I | 24V DC | Voltage/Current |
Technical Parameters
- Overvoltage Protection: ±30V continuous
- Common Mode Rejection: >120 dB @ 50/60 Hz
- Noise Rejection: 50/60 Hz @ 60 dB min
- Update Rate: 4ms per channel
- Burnout Detection: Current sources for TC
- Dielectric Strength: 1500V AC channel-to-bus
Installation Guide
- Mount on compatible Honeywell rack
- Connect 24VDC power (18-32V range)
- Wire signals respecting polarity
- Verify LED status indicators
- Configure in control system software
Compatibility
Designed for:
• Honeywell Experion PKS
• C300 Controller systems
• Series C I/O subsystems
Package Contents
- CC-PAIH51 module
- Installation documentation
Warranty & Shipping
12-month manufacturer warranty
FedEx, UPS, DHL global shipping
ESD-protected packaging
