CC-TDIL01 51308386-175 Honeywell Digital Input Module
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
Description
The Honeywell Series C Digital Input 24V IOTA (CC-TDIL01) board is an integral component designed for industrial automation and control systems. It interfaces digital input signals with the main control system, providing reliable and efficient data acquisition. This IOTA board is essential for monitoring and processing digital signals within various industrial environments.
Features
The CC-TDIL01 Digital Input 24V IOTA board is equipped with several features that enhance its functionality and reliability:
- Internal Protection Circuit: Safeguards the module and connected components from short circuits and other potential damage.
- Field Selectable Power: Allows for internal or external DI sense power using a jumper block (TB3), providing flexibility in configuration.
- Short Circuit Protection: Each input signal is protected against field short circuits, ensuring no damage to the module or board.
- Nonincendive and Non-arcing Protection: Suitable for Division 2 and Zone 2 environments, enhancing safety in hazardous areas.
- Independent Channel Protection: Ensures that short circuits in one channel do not affect other channels on the same IOM (Input/Output Module).
Specifications
The CC-TDIL01 Digital Input 24V IOTA board is designed to meet high standards of performance and reliability. Key specifications include:
- Input Voltage: 24V DC
- Field Wiring: Protected by internal circuits, allowing safe and reliable connections.
- Protection Circuit: Includes features for short circuit protection and current limiting.
-
Environmental Ratings:
- Operating Temperature: -20°C to +60°C (-4°F to +140°F)
- Storage Temperature: -40°C to +85°C (-40°F to +185°F)
- Compliance: Division 2 nonincendive / Zone 2 non-arcing protection.
Parts Information
The CC-TDIL01 Digital Input 24V IOTA board includes several components and accessories, each with its own specifications:
- Module: Main processing unit for digital input signals.
- IOTA (Input/Output Terminal Assembly): Interface for field wiring and signal conditioning.
- Terminal Plug-in Assembly: Facilitates easy and secure connections.
- Fuses: Provide overcurrent protection for the module and connected components.
Weight
- 0.3 kg (0.66 lbs)
