CI867A Ethernet Communication Interface Module

General Information

• Article Number: 3BSE092689R1
• Communication Protocol: MODBUS TCP
• Channels: 1 channel (Ch1)
• Speed: 10/100 Mbit/s (full duplex)

Features and Benefits

• The CI867A can be set redundant and supports hot swap.
• CI867A is a single channel Ethernet unit; Ch1 supports full duplex with 100 Mbps speed.
• Both master and slave functionality are supported.
• A maximum of 70 slave and 8 master units per CI867A can be used.

Functionality

• Master/Slave: Supports both configurations
• Redundancy: Module and hot swap supported

Capacity

• Max Units per Module: 70 slaves, 8 masters
• Max Units on CEX Bus: 12

Environmental Specifications

• Operating Temperature: +5 to +55 °C (+41 to +131 °F)
• Storage Temperature: -40 to +70 °C (-40 to +158 °F)
• Altitude: Up to 2000 m (6562 ft)
• Humidity: 5% to 95% non-condensing
• Protection Class: IP20

Certifications

• CE-marking: Yes
• Electrical Safety: UL 61010-1, UL 61010-2-201
• Hazardous Location: UL 60079-15, cULus Class 1, Zone 2, AEx nA IIC T4, ExnA IIC T4Gc X
• Marine Certifications: DNV-GL (Pending: ABS, BV, LR)
• Compliance: RoHS, WEEE

Dimensions

• Width: 59 mm (2.3 in.)
• Height: 185 mm (7.3 in.)
• Depth: 127.5 mm (5.0 in.)
• Weight (including base): 700 g (1.5 lbs)
