Honeywell 621-2175R Digital Output Module: High-Density Control

The Honeywell 621-2175R delivers reliable output control. This digital module offers thirty-two output points. Perfect for industrial automation systems.

Electrical Specifications

• Brand & Model:Honeywell 621-2175R
• Operating Voltage: 115 VAC power supply
• Output Voltage: 80-140 VAC range
• Number of Points: 32 individual channels
• Current per Point: 2A maximum rating
• Total Current: 12A module maximum
• Power Consumption: 8W efficient operation
• Insulation Resistance: 100MΩ high isolation

Physical Specifications

• Compact Design: 3.0 x 26.7 x 16.5 cm
• Lightweight Construction: Only 0.5 kg weight
• Mounting Style: DIN rail compatible
• Connection Type: Screw terminal blocks
• Enclosure Rating: Industrial protection
• LED Indicators: Per-point status lights

Environmental Specifications

• Operating Temperature: -20°C to +70°C
• Storage Temperature: -40°C to +85°C
• Humidity Range: 5-95% non-condensing
• Vibration Resistance: 2G operational
• Shock Resistance: 15G withstand
• EMC Compatibility: Industrial standards

Shipping & Warranty

• Worldwide shipping via FedEx, UPS, DHL
• Fast order processing
• Secure packaging protection
• 12-month warranty
• Technical support available
• Installation guide included

Frequently Asked Questions

• What load types can it drive? Resistive and inductive loads
• Is external power required? Needs 115VAC power supply
• What wiring is recommended? 14-18 AWG wire suggested
• Does it support diagnostics? Yes, LED status indicators
• Can it handle motor loads? Yes, with proper protection
