DS200TCPDG2BEC GE Power Module - Mark VI Distribution Board
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
GE Mark VI Power Distribution Module DS200TCPDG2BEC
- Premium Quality & Ready to Ship
- Complete 12-Month Protection
- Fast Global Express Delivery
- Full Testing Before Dispatch
Product Overview
The DS200TCPDG2BEC is a Power Distribution Module made by General Electric for Mark VI systems. This essential DS200TCPDG2BEC module manages power distribution in turbine control systems.
Technical Specifications
Brand: General Electric
Model: DS200TCPDG2BEC
Series: Mark VI
Product Type: Power Distribution Module
Input Voltage: 125 V DC
AC Input: 115/230 V AC
Power Conversion: AC to DC capability
Core Control: 8 individual power switches
Output Connectors: Multiple distribution points
Ignition Power: 120/240 V AC output
Solenoid Power: 125 V DC outputs
Ground Reference: BJS jumper isolated
Country of Origin: USA
Power Switch Functions
SW1: Controls R1 core power
SW2: Controls R2 core power
SW3: Controls R3 core power
SW4: Controls R5 core power
SW5: Controls R core power
SW6: Controls P1 core X power
SW7: Controls P1 core Y power
SW8: Controls P1 core Z power
Power Distribution
TCPS board power distribution
Control Engine core power
TCEA board power supply
Digital I/O core power
Terminal board power
Connector Functions
J1R, J1S, J1T: Core power distribution
J7W, J7X, J7Z: TCEA board power
J8A-J8D: Solenoid power outputs
J12A, J12B: Wetted contact inputs
JZ1-JZ5: Special function connections
Installation
Terminal block TB1 mounting
Labeled wire connections
Screw terminal security
Easy replacement procedure
Clear terminal identification
Warranty & Shipping
All products include 12-month full protection. Worldwide shipping via FedEx, UPS, and DHL. Quick dispatch guaranteed.
Professional FAQ
How many cores can be powered individually?
Eight separate cores can be powered individually using the front panel switches.
What power inputs are supported?
It accepts both 125V DC and 115/230V AC inputs with automatic conversion.
Does it power ignition transformers?
Yes, it provides 120/240V AC power for ignition transformers through JZ5 connector.
Can solenoid outputs be powered?
Yes, it provides 125V DC power for solenoid outputs through multiple J8 connectors.
Is external ground reference supported?
Yes, the BJS jumper allows isolation for external ground reference systems.
