DS200TCTGG1A GE GT/TMR Simplex Trip Board
Manufacturer:
GE
Product No.:
DS200TCTGG1A
Condition:
In Stock
Product Type:
GT/TMR Simplex Trip Board
Product Origin:
USA
Weight:
500g
Shipping port:
Xiamen
Warranty:
12 months
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
Technical Specifications
| Manufacturer | GE General Electric |
| Series | Mark V |
| Part Number | DS200TCTGG1A |
| Functional Description | Turbine Trip Board |
| Functional Acronym | TCTG |
| PCB Coating | Normal Coating |
| Operating Voltage | 24V DC nominal |
| Power Consumption | 15W maximum |
| Relay Contact Ratings | Max Current: 10A Max Voltage: 250V AC / 30V DC |
| Connector Pin Configuration | 50-pin connectors (JLY, JLX, JLZ): Standard pin-out for signal and power connections. 12-pin connectors (JN, JM): Configured for auxiliary signal connections. |
| Board Dimensions | 11.0 x 8.0 inches (27.94 x 20.32 cm) |
| Weight | Approximately 1.5 lbs (0.68 kg) |
| Environmental Operating Range | Temperature: -20°C to +60°C Humidity: 5% to 95% RH, non-condensing |
