EP11PTI100 HR13-MT Atlas Copco: Precision Shut-Off Ergopulse Tool

• Brand & Model: Atlas Copco EP11PTI100 HR13-MT. Origin is Sweden (SE).
• Torque Performance: Torque range min 52 ft-lb, max 74 ft-lb. Fixed transducer torque CCW service 105 Nm.
• Speed & Pulse: Free speed 5000 r/min. Pulsing freq. CCW 15-25 Hz. Pulse unit oil volume 18.4 ml.
• Air Requirements: Air consumption under load 30 cfm. Max working pressure 100 psi. Nominal working pressure 91 psi. Air inlet thread 3/8 in.
• Dimensions & Weight: Length 201 mm. Package 34.5 x 29.1 x 10.7 cm. Package weight 2.39 kg (3.7 lb). Output size 1/2" square drive.
• Noise & Vibration: Sound pressure 82.9 dB(A) per ISO15744. Vibration value 3.41 m/s² per ISO28927-2.
• Certifications: EAC certified. Meets EU 2006/42/EC (MD) and UK S.I. 2008/1597. Standards: EN/BS EN ISO 11148-6:2012.

Trim, AutoTrim & Shut-Off Functions

• Trim/AutoTrim: Enable fine adjustments for specialized applications.
• Shut-Off: Precise stopping at correct torque avoids over-tightening.
• TorqueBoost System: Delivers rapid torque without reaction force.

Frequently Asked Questions (FAQ)

• Q: What bolt size does this tool handle? A: M12 mm bolt size. CS distance 30.7 mm.
• Q: Is the tool suitable for complex applications? A: Yes, Ergopulse design handles high-speed complex tasks well.
• Q: Does it have vibration control? A: Vibration value 3.41 m/s² with uncertainty 0.76 m/s².
