Huawei ES0D0G48SC00 48-Port GE SFP Interface Board Overview

Engineers design the Huawei ES0D0G48SC00 switch line card for high-density optical data access in enterprise campus networks. This Huawei line card delivers forty-eight SFP slots that process wire-speed layer 2 and layer 3 traffic effortlessly. Network admins install this reliable ES0D0G48SC00 module into Huawei S7700 series chassis to improve overall data throughput quickly.

Product Architecture Summary

• Pyramid top: Enterprise core switches receive forty-eight high-speed optical connections through one single line board slot directly.
• Pyramid middle: Distributed packet forwarding engine offloads data traffic from main control units to enhance system stability.
• Pyramid base: SFP transceivers, copper converters, and smart LED status monitors ensure fast physical layer network diagnostics.

Technical Specifications

• Brand: Huawei
• Model Number: ES0D0G48SC00
• Product Category: 48-Port 100/1000BASE-X Optical Interface Board
• Port Density: 48 SFP slots supporting 100 Mbps and 1000 Mbps speeds
• MAC Table Capacity: 128K entries for large network routing tables
• Packet Buffer Memory: 4 MB dedicated internal packet cache memory
• Maximum Power Consumption: 92 Watts total operational heat output limit
• Compliant IEEE Standards: IEEE 802.3z for fiber optics and IEEE 802.3ab for copper connections
• Operating Temperature Range: 0°C to 45°C (32°F to 113°F) continuously
• Storage Temperature Limits: -40°C to +70°C (-40°F to 158°F) in non-condensing environments
• Operating Humidity Resistance: 5% to 95% RH non-condensing relative humidity tolerance
• Physical Dimensions: 394.7 mm Width x 426.8 mm Depth x 35.1 mm Height
• Unit Weight: 2.66 kg (5.86 lbs) net hardware weight

System Diagnostics and Status LEDs

• Upper and lower optical port LINK LEDs glow solid green when physical fiber connections establish normally.
• Upper and lower optical port ACT LEDs flash yellow during active data packet transmission and reception.
• RUN indicator flashes green slowly when internal card software operates without any network processing errors.
• RUN indicator flashes green rapidly during early card boot sequence steps after initial system power application.
• RUN indicator glows solid red whenever severe internal board hardware faults require immediate manual engineer intervention.
• RUN indicator glows solid yellow when operators force the board offline using system console shutdown commands.

Chassis Slot Compatibility Guide

• Engineers can slide cards into slots 01 through 03 inside Huawei S7703 chassis frames easily.
• Engineers can mount cards into slots 01 through 06 inside Huawei S7706 chassis frames securely.
• Engineers can populate slots 01 through 10 inside Huawei S7710 chassis frames without issues.
• Engineers can install cards into slots 01 through 12 inside Huawei S7712 chassis frames seamlessly.

Installation Guidelines

• Turn on grounding protection systems before touching sensitive electronic board parts inside chassis rack environments.
• Align board side rails carefully with guide slots inside target Huawei S7700 series switch chassis frames.
• Push card gently into chassis backplane until front panel locking levers snap firmly into place.
• Tighten front panel captive screws with proper tools to secure electrical connections against accidental removal.
• Insert compatible SFP optical transceivers into front panel ports before attaching LC fiber patch cables.

Package Contents and Logistics

• Package includes one Huawei high-density line card safely stored inside anti-static protective bubble bags.
• Package includes custom foam inserts inside sturdy cardboard shipping boxes to prevent transit damage.
• Shipping carrier options include fast international air express services via FedEx worldwide transport routes.
• Shipping carrier options include rapid global express delivery solutions handled by experienced UPS logistics networks.
• Shipping carrier options include reliable trackable air freight services provided directly through DHL international hubs.

Frequently Asked Questions

• Does this card support hot swapping? Yes, engineers can swap cards while switch chassis power remains fully active.
• Can I use copper SFP modules on these ports? Yes, ports accept copper SFP transceivers meeting IEEE 802.3ab networking guidelines.
• What network frame formats work with this board? The hardware processes Ethernet_II, Ethernet_SAP, and Ethernet_SNAP frames using native IP protocols.
