GE IS200EDEXG1B De-Excitation Bridge and Protection Board

The IS200EDEXG1B provides critical protection for excitation systems. This de-excitation board from General Electric safely disperses field energy during shutdowns. It features both controlled and backup triggering mechanisms for maximum reliability. The IS200EDEXG1B ensures your turbine generator system maintains safe operation under all conditions.

Technical Specifications

• Manufacturer: General Electric
• Model Number: IS200EDEXG1B
• Board Function: De-Excitation Bridge and Protection
• Compatible Series: EX2100 Innovation Series
• Operating Voltage: 24 VDC
• Configuration Jumpers: JP1, JP2, JP3, JP4, JP5, JP6
• Connector Type: 2 D-Pin Connectors
• Weight: 3 lbs 6 oz
• De-Excitation Method: Silicon-Controlled Rectifier (SCR)
• Protection Feature: Overvoltage Breakover Diode String
• Installation Location: Auxiliary Cabinet

System Integration

• Connects directly with EMIO and EXTB control boards
• Receives 24 VDC power from excitation system
• Mounts in auxiliary cabinet for easy maintenance access
• Works within EX2100 Innovation Series framework
• Complements overall turbine protection strategy

Installation & Configuration

• Reference GEH-6632 manual for installation guidance
• Utilize six configurable jumpers for system setup
• Connect via two D-pin connectors for secure interface
• Ensure proper mounting in auxiliary cabinet location
• Verify all electrical connections before operation

Shipping & Packaging

• Product ships in protective industrial packaging
• Available for immediate shipment worldwide
• We utilize FedEx, UPS, and DHL shipping services
• All items receive quality verification before dispatch

Frequently Asked Questions

• What is the primary function of this board? It provides de-excitation protection by safely dispersing field energy during generator shutdown using SCR technology.
• How does the backup protection work? If the SCR doesn't fire normally, overvoltage protection triggers when voltage exceeds the breakover diode threshold.
• What systems require this de-excitation board? EX2100 excitation systems and turbine generators needing controlled field energy dissipation during shutdown.
• What power does this board require? It operates on 24 VDC power supplied from the excitation control system.
• Where is this board typically installed? The board mounts in the auxiliary cabinet of the excitation control system for protection functions.
