Overview
The Bently Nevada 330130-060-13-00 is a high-performance extension cable designed for use with the 3300 XL 8 mm Proximitor Sensor. This cable features a robust design, incorporating advanced technologies to ensure reliable performance in industrial environments. The cable is available in a length of 6.0 meters (19.7 feet) and is manufactured in the U.S.A., meeting stringent quality standards. Additionally, it comes with a Certificate of Origin (COO) upon request.
Technical Specifications
- Brand: Bently Nevada
- Model: 330130-060-13-00
- Product Type: Extension Cable
- Cable Length: 060 (6.0 meters or 19.7 feet)
-
Connector Protector and Cable Option:
- 13: Armored FluidLoc cable with connector protector
- Approvals: 00 (Not required)
-
Weight:
- Armored Extension Cable: 103 g/m (1.5 oz/ft), 0.618 kg
-
Nominal Extension Cable DC Resistance:
-
RCORE (Ω) from Center Conductor to Center Conductor:
- Length: 6.0 m, RCORE: 1.32 ± 0.21
-
RJACKET (Ω) from Outer Conductor to Outer Conductor:
- Length: 6.0 m, RJACKET: 0.39 ± 0.08
-
RCORE (Ω) from Center Conductor to Center Conductor:
- Power Supply: Requires -17.5 Vdc to -26 Vdc, with a maximum consumption of 12 mA
- Output Resistance: 50 Ω
- Capacitance: 69.9 pF/m (21.3 pF/ft) typical
- Linear Range: 2 mm (80 mils), with operation beginning at 0.25 mm (10 mils) from the target
Furthermore, the enhanced design includes a patented TipLoc molding method and a CableLoc design for improved stability and pull strength.
