FBM207b Foxboro Voltage Monitor/Contact Sense Input Module
Manufacturer:
Foxboro
Product No.:
FBM207b
Condition:
In Stock
Product Type:
Input Module
Product Origin:
USA
Weight:
284g
Shipping port:
Xiamen
Warranty:
12 months
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
Key Features
- Accurate Pulse Counting: Ensures no missing pulses for rates up to 250 Hz.
- Configurable Filter/Debounce Time: Options include no filtering, 4 ms, 8 ms, 16 ms, or 32 ms.
- Redundant Power Input: Supports 24 V DC power input with a maximum consumption of 4 W.
- Loop Power Supply Protection: Current-limited to 3.2 mA (typical).
- Harsh Environment Suitability: Compliant with Class G3 as per ISA Standard S71.04.
- Vibration Resistance: Up to 7.5 m/s² from 5 to 500 Hz.
Technical Specifications
| Specification | Details |
|---|---|
| Input Voltage Range | Redundant 24 V DC +5%, -10% |
| Maximum Consumption | 4 W |
| Maximum Heat Dissipation | 4 W |
| Operating Temperature | -20°C to +70°C (-4°F to +158°F) |
| Operating Humidity | 5% to 95% (non-condensing) |
| Storage Temperature | -40°C to +70°C (-40°F to +158°F) |
| Storage Humidity | -5% to 95% (non-condensing) |
| Dimensions | 102 mm (H) x 45 mm (W) x 104 mm (D) |
| Weight | 284 g (10 oz) |
