Home » FBM214B P0927AH Foxboro Communication Input Module
Foxboro

FBM214B P0927AH Foxboro Communication Input Module

In stock
Manufacturer:
Foxboro
Product No.:
FBM214B
Condition:
In Stock
Product Type:
Communication Input Module
Product Origin:
USA
Weight:
284g
Shipping port:
Xiamen
Warranty:
12 months

UBEST – Trusted Global Automation Parts Supplier

We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.

About Us | Contact

Technical Specifications

Manufacturer Honeywell
Model FBM214B P0927AH
Interface 8 individually isolated channels
Power Requirements
  • Input Voltage Range (Redundant): 24 V DC +5% -10%
  • Consumption: 7 W (maximum)
  • Heat Dissipation: 4 W (maximum)
Operating
  • Temperature (Module): -20 to +70°C (-4 to +158°F)
  • Temperature (Termination Assembly): -20 to +70°C (-4 to +158°F)
  • Relative Humidity: 5 to 95% (noncondensing)
  • Altitude: -300 to +3,000 m (-1,000 to +10,000 ft)
Storage
  • Temperature: -40 to +70°C (-40 to +158°F)
  • Relative Humidity: 5 to 95% (noncondensing)
  • Altitude: -300 to +12,000 m (-1,000 to +40,000 ft)
Vibration 7.5 m/S² (0.75 g) from 5 to 500 Hz
Cable Connection – TA FBM Baseplate End: 37-pin D-subminiature
Termination Assembly End: 25-pin D-subminiature
Weight
  • Module: 284 g (10 oz) approximate
  • Termination Assembly (Compression): 181 g (0.40 lb) approximate
Dimensions – Module
  • Height: 102 mm (4 in)
  • Height (including mounting lugs): 114 mm (4.5 in)
  • Width: 45 mm (1.75 in)
  • Depth: 104 mm (4.11 in)
