FBM239 Foxboro Discrete DI/DO Interface Module
Manufacturer:
Foxboro
Product No.:
FBM239
Condition:
In Stock
Product Type:
Discrete DI/DO Interface Module
Product Origin:
USA
Weight:
280g
Shipping port:
Xiamen
Warranty:
12 months
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
Foxboro 🖥️ Product Information
| Model: FBM239 P0927AG |
| Product Type: Discrete 16DI/16DO Interface Module |
Foxboro 🔧 Operational Specifications
| Input Signal Voltages Supported: |
| - 30 V dc/60 V dc |
| - 120 V ac/125 V dc |
| - 240 V ac |
| Output Switching Voltages Supported: |
| - 60 V dc |
| - 120 V ac/125 V dc |
| - 240 V ac |
Foxboro ⚙️ Electrical Characteristics
| Input: |
| - Maximum Applied Voltage: 30 V dc |
| On-State Voltage: 15 to 30 V dc |
| Off-State Voltage: 0 to 5 V dc |
| Current Input for On-State: 2.3 mA max at 30 V dc |
| Source Resistance Limits On-State: 1 kΩ (max) at 15 V dc |
| Source Resistance Limits Off-State: 100 kΩ (min) at 30 V dc |
Foxboro ⚡ Power and Environmental Specifications
| Contact Supply: 24 V dc nominal (supplied by FBM through the TA) |
| Contact Current: 1.8 mA dc nominal |
| Power Requirements: |
| - Input Voltage Range: 24 V dc +5%, -10% |
| - Module Consumption: 2.65 W (max) at 24 V dc |
| - Module Heat Dissipation: 5.3 W (max) at 2 A total load and all inputs at 30 V dc |
Foxboro 🌡️ Operating and Storage Conditions
| Operating Temperature: -20 to +70°C (-4 to +158°F) |
| Operating Relative Humidity: 5 to 95% (noncondensing) |
| Operating Altitude: -300 to +3,000 m (-1,000 to +10,000 ft) |
| Storage Temperature: -40 to +70°C (-40 to +158°F) |
| Storage Relative Humidity: 5 to 95% (noncondensing) |
| Storage Altitude: -300 to +12,000 m (-1,000 to +40,000 ft) |
