FC-TSDO-0824 Safe Digital Output FTA Honeywell FSC
Manufacturer:
Honeywell
Product No.:
FC-TSDO-0824
Condition:
In Stock
Product Type:
Safe Digital Output FTA
Product Origin:
USA
Weight:
300g
Shipping port:
Xiamen
Warranty:
12 months
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
FC-TSDO-0824 Safe Digital Output FTA
(24 V DC, 8 channels)
Technical Data
| Category | Specification |
|---|---|
| Type numbers | FS-TSDO-0824, FC-TSDO-0824 |
| Approvals | CE, TUV, UL, CSA, FM |
Power
| Parameter | Specification |
|---|---|
| Number of channels | 8 |
| Maximum voltage | 36 V DC - IEC 1010 (1990), Overvoltage category 3 (Table D.12) |
| Maximum continuous current per channel | 1.5 A |
| Actual maximum current | Defined by connected output module |
Physical
| Parameter | Specification |
|---|---|
| Module dimensions | 60 × 70 × 58 mm (L × W × H) 2.36 × 2.76 × 2.28 in (L × W × H) |
| DIN EN rails | TS32 / TS35 × 7.5 |
| Used rail length | 61 mm (2.40 in) |
| Termination | Screw terminals: - Max. wire diameter: 2.5 mm² (AWG 14) - Strip length: 7 mm (0.28 in) - Tightening torque: 0.5 Nm (0.37 ft-lb) |
