GE Fanuc IC200CHS006 Communications Carrier | VersaMax Series

The IC200CHS006 from GE Fanuc provides essential mounting and connectivity for VersaMax communication modules. This robust carrier ensures reliable field wiring and backplane communications in industrial environments.

Key Technical Specifications

• Brand: GE Fanuc
• Model: IC200CHS006
• Type: Communications Carrier
• Dimensions: 66.8 x 133.4 mm
• Mounting: Standard DIN rail (7.5 x 35 mm)
• Operating Temperature: 0 to 60°C
• Storage Temperature: -40 to 85°C
• EMC Protection: Requires grounded DIN rail

Compatibility & Supported Modules

• Works with all VersaMax Fieldbus communication modules
• Compatible with IC200BEM002 Profibus-DP network slave module
• Supports IC200BEM103 DeviceNet network control module
• Accommodates IC200BEM104 AS network master module
• Features latch hole for secure module fastening

Installation Guidelines

• Snap easily onto standard 35mm DIN rail mounting
• Ensure DIN rail has conductive corrosion-resistant finish
• Ground the DIN rail properly for EMC protection
• Install in any available slot within your system
• Use panel mounting for vibration-resistant applications

Operational Features

• Draws power from main supply or booster power supply
• Enables data exchange on Profibus networks
• Supports multiple Profibus-DP modules in same PLC
• Allows DeviceNet configuration as slave or master
• Provides AS Interface connectivity for sensor networks

Packaging & Shipping

• Includes one GE Fanuc IC200CHS006 communications carrier
• Worldwide shipping via FedEx, UPS, and DHL services
• All orders include complete tracking information
