GE Fanuc IC200ALG260 VersaMax 8-Channel Analog Input Module
Product Overview
The GE Fanuc IC200ALG260 is a high-density analog input module for VersaMax systems. It features 8 configurable inputs for voltage or current signals. Provides precise measurements. Ideal for multi-point monitoring.
Key Benefits
8 analog inputs. 12-bit resolution. Flexible voltage/current selection. Fast 0.4ms update. LED status lights. No external power needed.
Technical Specifications
Brand: GE Fanuc
Series: VersaMax
Model: IC200ALG260
Module Type: Analog Input Module
Input Channels: 8 (Single-Ended)
Resolution: 12 Bits
Voltage Ranges: ±10V DC (Bipolar), 0-10V DC (Unipolar)
Current Range: 4-20 mA
Update Rate: 0.4 ms
Filter Response: 5.0 ms
Accuracy: ±0.3% Typical, ±1.0% Maximum (0-60°C)
Input Impedance: 126 kΩ (Voltage), 200 Ω (Current)
Backplane Current: 130 mA at 5V DC Maximum
Isolation: 250V AC Continuous, 1500V AC for 1 min
LED Indicators: INT PWR, OK
Crosstalk Rejection: >30 dB
Operating Temperature: 0 to 60°C
Error Response: Hold Last State or Go to Default Value
Package Contents
One (1) GE Fanuc IC200ALG260 analog input module. Installation guide.
Simple Installation
Install in any VersaMax carrier. Configure via software for voltage or current mode. Connect signals to terminal block. No external power required.
High-Density Inputs
This IC200ALG260 module provides 8 channels in a compact design. Perfect for applications needing multiple analog measurements.
Frequently Asked Questions
-
How many signals can it handle?
It can process up to 8 analog signals simultaneously. -
What types of signals does it accept?
It accepts voltage signals (±10V or 0-10V) and current signals (4-20mA). -
What is the measurement accuracy?
It offers high accuracy of ±0.3% typical at 25°C. -
Does it need separate power?
No, it receives all necessary power from the VersaMax backplane. -
What is the input impedance?
Impedance is 126 kΩ in voltage mode and 200 Ω in current mode.
