GE Fanuc IC200ALG325 VersaMax Analog Output Module

The GE Fanuc IC200ALG325 delivers precision control for your VersaMax system. This analog output module provides eight configurable voltage outputs. It operates reliably in industrial environments without thermal derating.

Technical Specifications

• Brand: GE Fanuc
• Series: VersaMax
• Model: IC200ALG325
• Module Type: Analog Output Module
• Output Channels: 8 single-ended
• Output Voltage: -10 to +10V DC (bipolar), 0 to 10V DC (unipolar)
• Resolution: 13 bits
• Update Rate: 10 ms maximum
• External Power: 18-30V DC required
• Backplane Current: 50 mA at 5V DC maximum
• Isolation: 250V AC continuous, 1500V AC for 1 minute
• Operating Temperature: 0 to 60°C
• Accuracy Variation: 1% maximum
• LED Indicators: OK status indicator
• Diagnostics: Power loss detection

Installation Guide

• Install in any compatible VersaMax carrier
• Connect external power supply (18-30V DC)
• Use shielded cables for output connections
• Configure output ranges through software
• Verify proper operation using status LED

Package Contents

• One IC200ALG325 analog output module
• Comprehensive installation manual
• Mounting accessories

Shipping Information

• Available for immediate shipment
• Global delivery via FedEx, UPS, DHL
• Tracking provided for all orders

Frequently Asked Questions

• What voltage outputs does it provide?
  This module offers both bipolar (-10 to +10V) and unipolar (0 to 10V) outputs.
• Does it need external power?
  Yes, it requires an external 18-30V DC power supply for output operation.
• What is the resolution?
  The module provides 13-bit resolution for precise analog output control.
• How many output channels are available?
  There are eight single-ended output channels in one group.
• What diagnostics are included?
  The module features power loss detection and status monitoring.
