GE Fanuc IC200PNS001 PROFINET Interface | Versamax Network Module
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
GE Fanuc IC200PNS001: Versamax PROFINET Network Interface Unit
Connect your automation system with the advanced IC200PNS001 PROFINET interface. This GE Fanuc Versamax module enables seamless industrial networking for distributed I/O systems. It supports high-speed data exchange and multiple network topologies for flexible installation.
Technical Specifications
- Brand: GE Fanuc (Emerson)
- Series: Versamax
- Model: IC200PNS001
- Type: PROFINET Network Interface Unit
- Protocol: PROFINET V2.2 Class A IO-Device
- Ports: 2 RJ45 (10/100 Mbps)
- Discrete I/O: 2880 bytes total (1440 in/1440 out)
- Analog I/O: 2880 bytes total (1440 in/1440 out)
- Update Rates: Configurable 1ms to 512ms
- Max Modules: 8 Versamax I/O modules
- Power Consumption: 3W at 5VDC (0.6A)
- Cable Distance: 100 meters per segment
- Temperature Range: 0°C to 60°C
- Dimensions: 134mm x 132mm
- Compatibility: PACSystem RX3i, RX7i, Series 90-70
- Software: Proficy Machine Edition V7.0+
Easy Installation
The IC200PNS001 module mounts on standard DIN rail. It connects easily to Versamax I/O modules and carriers. The dual Ethernet ports allow daisy-chaining without additional switches.
System Compatibility
This IC200PNS001 interface works with multiple controller platforms. It connects Versamax I/O to PROFINET networks seamlessly. The module supports various network topologies for flexible installation.
Warranty & Support
We provide a 12-month warranty on this product. Our technical team offers networking and configuration support.
Global Shipping
We ship worldwide using FedEx, UPS, and DHL. All orders include complete tracking and insurance coverage.
Frequently Asked Questions
Q1: What controllers work with this PROFINET interface?
A1: It works with PACSystem RX3i, RX7i, and Series 90-70 controllers with firmware V7.0+.
Q2: How many I/O modules can be connected?
A2: Up to 8 Versamax I/O modules can be connected to each IC200PNS001 interface.
Q3: What is the maximum data update rate?
A3: The fastest update rate is 1ms, with configurable options up to 512ms.
Q4: Does this module support redundant networks?
A4: Yes, it supports ring topology for network redundancy and increased reliability.
Q5: What software is required for configuration?
A5: Proficy Machine Edition version 7.0 or later is required for setup and programming.
