GE Fanuc IC697MDL671 Input Module: Versatile 16-Point DC Interface

Key Features

• 16-point DC input module for industrial automation
• Flexible 24V DC operation (-3V to +30V range)
• Supports both positive and negative logic
• Works with proximity switches and sensors

Technical Specifications

• Brand/Model: GE Fanuc IC697MDL671
• Input Voltage: -3V to +30V DC
• Input Current: 10mA typical
• Isolation: 1500V protection
• Response Time: Selectable 1ms or 10ms filter
• Point Configuration: 16 inputs (4 groups of 4)
• Power Consumption: 0.3A @5V DC

Flexible Input Options

• Wide voltage acceptance:
  • ON state: 13.5V-30V
  • OFF state: -3V to +5V (pos), -5V to +30V (neg)
• Selectable input filtering for noise immunity
• Industrial proximity sensor compatible

Installation Benefits

• Simple backplane mounting
• Grouped isolation (4 points per group)
• Compact 0.52kg design saves space
• Ideal for high-speed counting applications

Package & Support

• Includes: IC697MDL671 module
• 12-month warranty
• Global shipping: FedEx/UPS/DHL

Expert FAQs

• Q: What PLCs is this compatible with?
  GE Fanuc 90-70 series controllers
• Q: Can I mix positive/negative logic?
  Yes - each input accepts both types
• Q: What's the maximum input frequency?
  1ms filter: 500Hz, 10ms filter: 50Hz
• Q: Is external power needed?
  No - powered via PLC backplane
• Q: How many modules per rack?
  Limited by power supply capacity
