GE Fanuc IC697VAL348 8-Channel DAC Converter Board
Product Overview
The GE Fanuc IC697VAL348 is a digital-to-analog converter for Series 90-70 systems. It converts digital signals to precise analog voltages. Features 8 independent channels. Perfect for control and measurement applications.
Key Benefits
8-channel DAC. 16-bit high resolution. 10V output. Front panel fault LED. DIN connector. Double Eurocard form. Easy configuration.
Technical Specifications
Brand: GE Fanuc
Series: Series 90-70
Model: IC697VAL348
Module Type: Digital-to-Analog Converter Board
Channels: 8 Independent
Resolution: 16 Bits
Output Voltage: 10 Volts
Output Current: 5 mA per channel
Connector: High-Reliability DIN
Form Factor: Double Eurocard
Configuration: 6 Factory Jumpers
Indicators: Front Panel Fail LED
Input Codes: Positive Binary, Two's Complement
Mounting: Any VME Slot (Except Master Processor)
Installation: Power-Off Required
Package Contents
One (1) GE Fanuc IC697VAL348 converter board. Installation manual.
Easy Installation
Install in any VMEbus slot except the master processor slot. Ensure power is off during installation. Check factory jumper settings before use.
Configuration Options
This IC697VAL348 board includes configurable jumpers for base address selection, address modifier, digital code format, and operation mode.
Frequently Asked Questions
How many channels does it have?
It provides 8 independent digital-to-analog conversion channels.
What is the output voltage range?
Each channel provides a buffered output voltage up to 10 volts.
What is the resolution?
It offers high precision with 16-bit resolution for accurate analog output.
How is it configured?
Configuration is done through six factory jumpers for various operating modes.
What does the LED indicator show?
The front panel LED indicates fault conditions during operation.
Shipping & Warranty
Shipped globally via FedEx, UPS, and DHL. Protected by a 12-month warranty.
