GE Fanuc IC754VSI06MTD QuickPanel Operator Terminal

The GE Fanuc IC754VSI06MTD is a versatile operator panel from the QuickPanel product line. This terminal enables straightforward machine interface through both monochrome and color display options. Designed for industrial applications, it provides reliable operation with flexible configuration capabilities for various automation requirements.

Key Technical Specifications

• Manufacturer & Model: GE Fanuc IC754VSI06MTD | QuickPanel
• Display Options: Monochrome display or color flat-panel model available
• Display Size: 6-inch diagonal measurement for clear visualization
• Color Model: 5.7-inch passive STN technology with backlight
• Input Method: Touchscreen interface for direct operator interaction
• Power Requirements: 12-30 VDC input voltage for flexible installation
• Internal Memory: 32 MB memory for application storage and operation

Communication & Interface Features

• Serial Communication: RS232 port for point-to-point device connection
• Network Communication: RS485 port for multi-drop networked systems
• Communication Cable: Compatible with HMI-CAB-C120 interface cables
• Data Exchange: Enables communication with machines and control systems
• Connection Flexibility: Supports various industrial communication setups
• System Integration: Facilitates connectivity within automation environments

Display & Input Capabilities

• Display Technology: Passive STN technology for color model variant
• Backlight System: Integrated backlight with timer functionality
• Backlight Management: Automatic shutoff extends backlight operational life
• Touch Activation: Requires activation before initial use each session
• Input Tools: Works with fingers but recommends blunt stylus for precision
• Visual Interface: Clear display enhances operator interaction with machines

Physical & Operational Specifications

• Unit Weight: 2.00 lbs (0.91 kg) for lightweight installation and handling
• Display Variants: Choice between monochrome and color display options
• Operator Interface: Simplifies machine interaction for various user levels
• Data Input: Supports both direct touch and software keyboard entry
• Power Flexibility: Wide voltage range accommodates different power sources
• Connection Simplicity: Makes machine connections straightforward for users

Configuration & Setup Procedures

• Input Panel Setup: Double-tap input panel in control panel to begin configuration
• System Tray Control: Select or clear "show input panel in system tray" option
• Application Selection: Choose allowed applications for input panel display
• Settings Confirmation: Tap "okay" to confirm configuration changes
• Backup Execution: Run backup utility to save all configuration settings
• State Management: Change input panel state checkbox as needed

Operational & Functional Benefits

• Simplified Interface: Provides easy machine interaction for operators
• Flexible Input: Multiple input methods accommodate different preferences
• Energy Efficiency: Backlight timer reduces power consumption
• Display Longevity: Backlight management extends operational lifespan
• Data Management: Adequate memory supports application requirements
• Industrial Design: Built for reliable performance in factory environments

Package Contents & Shipping

• GE Fanuc IC754VSI06MTD QuickPanel Operator Terminal
• Communication cable (HMI-CAB-C120 compatible)
• Mounting hardware and installation accessories
• Documentation and configuration guidelines
• Global shipping via FedEx, UPS, and DHL services
• Available for industrial automation system integration

Professional Application FAQ

• What are the advantages of having both monochrome and color options?

The IC754VSI06MTD offers flexibility - monochrome for cost-effective applications where color isn't essential, and color for enhanced visualization where different status indicators improve operator understanding.

• How does the backlight timer feature extend display life?

The automatic backlight shutoff reduces cumulative operating hours, significantly extending the backlight's lifespan while conserving energy during periods of operator inactivity.

• Why is a blunt stylus recommended over finger touch?

A blunt stylus provides more precise touch activation, reduces screen wear, and works better with industrial gloves, while minimizing accidental touches compared to finger operation.

• What benefits does the software emulation keyboard provide?

The software keyboard eliminates need for physical keyboard hardware, saves panel space, provides customizable layouts, and integrates seamlessly with the touchscreen interface.

• How straightforward is the configuration process for new users?

Configuration follows logical steps through the control panel interface, with clear options for input panel management and straightforward backup procedures to secure settings.
