GE Fanuc IC200MDL635: 16-Point 48VDC Input Module
Upgrade your control system with the high-density IC200MDL635 input module. This Versamax module provides 16 discrete inputs in two isolated groups. It supports both positive and negative logic wiring for maximum flexibility in your industrial applications.
Technical Specifications
- Brand: GE Fanuc
- Series: Versamax
- Model: IC200MDL635
- Type: Digital Input Module
- Input Points: 16 (2 groups of 8)
- Voltage: 48 VDC Nominal (0-60 VDC Range)
- Input Current: 1.7mA @ 48VDC, 2.1mA @ 60VDC
- Response Time: 0.5ms (On/Off)
- Isolation: 1500VAC (group to group)
- Logic Support: Positive & Negative
Easy Installation
The IC200MDL635 module snaps easily into any Versamax carrier. No extra power supply is needed. The grouped design simplifies wiring for large applications.
System Compatibility
This IC200MDL635 module is fully compatible with all Versamax PLC systems and racks. It integrates seamlessly into existing setups.
Warranty & Support
All products include a 12-month warranty. Our technical team provides expert support for installation and troubleshooting.
Global Shipping
We ship worldwide via FedEx, UPS, and DHL. All orders include full tracking and insurance for peace of mind.
Frequently Asked Questions
- Q1: How are the 16 inputs grouped on the IC200MDL635?
- A1: They are arranged in two separate groups of 8 points each. Each group shares a common connection.
- Q2: What is the isolation rating between groups?
- A2: The groups are isolated from each other with a 1500VAC rating for one minute.
- Q3: Can I mix positive and negative logic in the same group?
- A3: No, all inputs within a single group must use the same logic type (positive or negative).
- Q4: What is the minimum operating voltage for this module?
- A4: The module can detect signals as low as 5 VDC, though nominal operation is at 48 VDC.
- Q5: Does this module require external power?
- A5: No, it receives all necessary power from the Versamax backplane connection.
