GE IS215VCMIH2CC Bus Master Controller - System Communication Hub

General Electric's IS215VCMIH2CC serves as the central communication controller for Mark VI systems. This VME bus master ensures seamless data exchange between controllers and I/O components.

Technical Specifications

• Brand: General Electric
• Model: IS215VCMIH2CC
• Product Type: Bus Master Controller Module
• Series: Mark VI Control System
• Operating Temperature: -30°C to +65°C
• Storage Temperature: -40°C to +85°C
• Board Format: 6U High VME Standard
• Board Width: 0.787 inches (20 mm)
• Board Height: 6U (233.35 mm)
• Technology: Surface-mount components

Processor & Memory Configuration

• Main Processor: Texas Instruments TMS320C32
• Architecture: 32-bit Digital Signal Processor
• Clock Speed: 40 MHz operating frequency
• Dual-Port Memory: 32 KB SRAM capacity
• Main SRAM: 64K x 32 configuration
• Flash Memory: 128K x 8 storage
• Data Transfer: 32-bit parallel bus
• Processing Power: 20 MIPS performance

Communication & Interface

• VME Bus Master functionality
• IONet system control network
• Multiple I/O board coordination
• Real-time data exchange
• Controller interface management
• Network synchronization
• Data transfer optimization
• System integration support

System Management Functions

• Automatic board ID assignment
• Terminal board recognition
• Rack component management
• System configuration control
• Communication coordination
• Data flow optimization
• Error detection capability
• System diagnostics support

Electrical Characteristics

• Operating Voltage: +5 V DC primary
• Current Consumption: 1.2A maximum
• Power Requirement: 6 watts typical
• Signal Levels: TTL compatible
• Bus Speed: 40 MB/s maximum
• Noise Immunity: Industrial grade
• EMI Protection: Shielding included
• Ground Isolation: Standard feature

Installation Guidelines

• Install in compatible VME chassis
• Ensure proper slot alignment
• Connect all required cables
• Verify power supply compatibility
• Check board seating in slot
• Confirm connector engagement
• Power up system gradually
• Validate system recognition

Package Contents

• One IS215VCMIH2CC controller board
• Installation documentation
• Mounting accessories
• Technical specifications sheet
• Protective packaging materials

Shipping Options

• FedEx express delivery service
• UPS worldwide shipping
• DHL international delivery
• Package tracking provided
• Secure packaging ensured
• Quick dispatch processing

Warranty Information

• 12-month product warranty
• Technical support included
• Quality assurance guarantee
• Replacement service
• Customer assistance

Professional FAQ

• What processor does this controller use?
• The board features a Texas Instruments TMS320C32 32-bit digital signal processor for high-speed data processing and control functions.
• How much memory is available on the board?
• It includes 32KB dual-port SRAM, 64K x 32 main SRAM, and 128K x 8 flash memory for program storage and data handling.
• What communication networks does it support?
• The controller manages VME bus communication and interfaces with IONet system control networks for comprehensive data exchange.
• Can it manage multiple I/O boards?
• Yes, it automatically assigns unique identification to all connected boards and coordinates data transfer between them efficiently.
• What is the operating temperature range?
• The controller operates reliably in industrial environments from -30°C to +65°C with proper thermal management.
