Bently Nevada 330707-00-20-50-12-00 3300 XL 11mm Proximity Probe

Get the Bently Nevada 330707-00-20-50-12-00 for reliable machinery monitoring. This sensor is part of the 3300 XL Series. It features a 5-meter armored cable for tough industrial environments. We guarantee authenticity and fast global delivery.

Technical Specifications

• Brand: Bently Nevada
• Series: 3300 XL
• Model: 330707-00-20-50-12-00
• Type: Proximity Probe
• Cable Length: 5.0 meters (16.4 feet)
• Thread Size: 1/2-20 UNF
• Case Material: AISI 304 Stainless Steel (SST) with Armor
• Operating Temp: -51°C to +177°C (-60°F to +351°F)
• DC Resistance: 7.2 ± 0.8 ohms
• Connector Type: Miniature Coaxial ClickLoc

Decoding the Model Number

Understand every part of your Bently Nevada 330707-00-20-50-12-00 probe:

• Base Code (330707): 3300 XL 11 mm Probe with 1/2-20 UNF thread and armor
• Suffix 1 (00): Unthreaded Length = 0 inches
• Suffix 2 (20): Overall Case Length = 2.0 inches
• Suffix 3 (50): Total Length = 5.0 meters (Designed for 5m Proximitor Sensor)
• Suffix 4 (12): Miniature coaxial ClickLoc connector with FluidLoc cable
• Suffix 5 (00): Agency Approval = Not required

Installation & Handling

Follow these tips for your 330707-00-20-50-12-00 probe:

• Thread Torque: Recommended 15.2 N•m (133 in•lb). Maximum 45.2 N•m (400 in•lb).
• Engagement Depth: Do not exceed 0.750 inches for 1/2-20 probes.
• Bend Radius: Keep the cable bend above 25.4 mm (1.0 inch).
• Connector Care: Tighten the connector only finger-tight. Do not exceed 0.565 N•m.

Performance & Compatibility

This Bently Nevada probe works with 3300 XL systems. It seals differential pressure using a Viton O-ring. Avoid using it below -34°C (30°F) to prevent seal damage. The 5-meter length suits specific long-distance monitoring needs.

Warranty & Shipping

Buy with confidence. We offer a 12-month warranty on this Bently Nevada sensor. We ship worldwide using FedEx, UPS, and DHL. We ensure fast delivery for urgent industrial needs.

Frequently Asked Questions

Q: Why is the 5-meter cable length important for this model?

A: The 5-meter cable (Code 50) is designed specifically for use with the 5-meter Proximitor Sensor. It ensures the correct signal length for accurate vibration monitoring.

Q: What does the "Armor" feature do on this probe?

A: The armor (indicated in the base code 330707) is made of stainless steel. It protects the cable from physical damage, cuts, and abrasion in harsh industrial settings.

Q: What is the DC resistance value for this 5-meter probe?

A: The DC resistance from the center conductor to the outer conductor is 7.2 ohms. The acceptable range is 7.2 ± 0.8 ohms.

Q: Can I use this probe in very cold temperatures?

A: The operating range is -51°C to +177°C. However, exposing the probe to temperatures below -34°C may cause the pressure seal to fail early.

Q: What is the difference between the ClickLoc and other connectors?

A: The ClickLoc connector (Code 12) features a miniature coaxial design. It includes a connector protector and FluidLoc cable for better sealing against fluids.
