GT27-V4-Z Video Input Unit – Reliable Analog Video for GOT2000 HMI

Technical Specifications at a Glance

• Manufacturer: Mitsubishi Electric
• Product Line: GOT2000 Series
• Part Number: GT27-V4-Z
• Device Type: Dedicated video input unit
• Applicable Models: GT27 series HMIs
• Video Input Channels: 4 x composite video (BNC)
• Synchronization Signal: 1 Vp-p with 75 Ω impedance
• Resolution: 640 x 480 VGA
• Current Consumption: 0.32 A @ 3.3 V DC / 0.34 A @ 5.0 V DC
• Weight (unit only): 1.36 kg (3.00 lbs)
• With GT27-IF1000 interface converter: approx. 0.34 kg total

Frequently Asked Questions (FAQ)

• Q: Does the GT27-V4-Z support HD or digital video?
  A: No, it accepts analog composite video (NTSC/PAL) only. It is ideal for standard CCTV or analog camera sources.
• Q: Can I display all 4 channels simultaneously on the HMI?
  A: Each channel displays one video input at a time. You can switch between channels via the HMI software.
• Q: Which Mitsubishi HMI models work with this video unit?
  A: It is specifically designed for GT27 models within the GOT2000 series. It does not fit GT21 or GT25 without the proper interface converter.
• Q: What is the maximum cable length for BNC connection?
  A: We recommend staying under 30 meters (98 ft) to maintain signal quality without external amplifiers.
• Q: Is the GT27-IF1000 interface converter mandatory?
  A: It depends on your system configuration. Use it when connecting long-distance video sources or when isolation is required.
• Q: Does the unit come with software drivers?
  A: The Mitsubishi GOT2000 firmware natively supports the video input unit; no separate driver installation is needed.
