F7126 Power Supply Module: Reliable 24V to 5V DC Conversion for PES H51q
The F7126 power supply module delivers stable 5V DC power for your automation systems. Convert 24V DC input to precise 5V output with complete safety isolation.
- Quick Delivery - Ships via FedEx, UPS, DHL Worldwide
- Full Protection - 12-month quality warranty included
- Easy Installation - Ready for PES H51q systems
- Safety Certified - Overvoltage and short-circuit protection
Technical Specifications
Model: F7126 Power Supply Module
Input Voltage: 24V DC (-15% to +20%)
Output Voltage: 5V DC ±0.5V (adjustable)
Maximum Current: 10A output capacity
Current Limit: Approximately 13A protection
Efficiency: ≥77% energy conversion
Overvoltage Protection: 6.5V ±0.5V cutoff
Input Fuse: 6.3A slow-blow type
Isolation: Safe isolation between input and output
Space Requirement: 8 TE panel units
Ripple: <15% peak-to-peak
Factory Setting: 5.4V ±0.025V initial calibration
Key Features
High Power Output - Delivers 10A at 5V DC
Complete Protection - Short-circuit and overvoltage safety
Easy Adjustment - Front potentiometer for voltage tuning
Redundant Ready - Balanced load capability for backup systems
Test Socket - Front panel access for voltage monitoring
Frequently Asked Questions
What is the input voltage range for the F7126 module?
It accepts 24V DC with -15% to +20% tolerance.
Can I adjust the output voltage?
Yes, use the front potentiometer to fine-tune between 4.5V and 5.5V.
What protection features are included?
Overvoltage protection, current limiting, and short-circuit proof output.
How efficient is the power conversion?
At least 77% efficient, reducing energy waste.
Can multiple F7126 modules work together?
Yes, for redundant systems, keep output voltages within 0.025V difference.
Warranty & Shipping
Every F7126 power supply module includes 12-month warranty. Fast international shipping via FedEx, UPS, and DHL available.
