Honeywell 900ES1-0100 Serial Communication Module
Manufacturer:
Honeywell
Product No.:
900ES1-0100
Condition:
In Stock
Product Type:
Serial Communication Module
Product Origin:
USA
Weight:
350g
Shipping port:
Xiamen
Warranty:
12 months
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
Description
The Serial Communication Module (900ES1-0100) provides two RS232 ports and two RS485 ports. It supports Modbus Serial communication protocols and user-defined protocols.
Item Specification
| Item | Specification |
|---|---|
| Protocol Support |
- Modbus ASCII Master - Modbus ASCII Slave - Modbus RTU Master - Modbus RTU Slave - User defined Protocol |
| Connector |
- 2 x RS232: 9-Pin D-sub male connector, share the same isolator - 2 x RS485: Isolated from each other and from RS232 ports |
| Galvanic Isolation | 2000 VDC |
| Maximum Slave Devices Connected per RS485 Port | 32 |
| Module Status LED | Supported |
| Channel Communication LED | Supported |
| Maximum Communication Module per CPM | 6 |
| Operation Temperature | -40 to 70°C |
| Storage Temperature | -40 to 85°C |
| Baud Rate | 300bps to 115200bps, adjustable |
| Flow Control | None, RTS-CTS, RTS |
| Parity | None, Odd, Even |
| Data Bits | None, Odd, Even |
| Stop Bits | 7, 8 (7 is not supported on Modbus RTU protocol) |
| Experion Integration – Diagnostic | Supported |
| Maximum Length of User Defined Protocol | 532 Bytes |
| Supported Data Types on User Defined Protocol | USINT, UINT, UDINT, LINT, REAL, LREAL |
| Dimension | 137mm H x 35.6mm W 5.4" H x 1.4" W |
| Weight | 350g |
