Honeywell Termination Module 10313/1/1
Manufacturer:
Honeywell
Product No.:
10313/1/1
Condition:
In Stock
Product Type:
Termination Module
Product Origin:
USA
Weight:
300g
Shipping port:
Xiamen
Warranty:
12 months
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
10313/1/1 Module: FSC System Power Distribution and Watchdog Signal Unit
Technical Specifications
- Model:10313/1/1 207011
- Type: Power Distribution Module
- Approvals: CE, TÜV (UL pending)
- Max Current Faston Pin: 4A
- Max Current I/O Pin: 2A
- Dimensions: 240x87x60 mm
- Weight: 0.3 kg
- Rail Type: TS32 / TS35 x 7.5
- Rail Length: 241 mm
- Voltage: 5V DC
- Operating Temp: 0°C to 60°C
- Storage Temp: -40°C to 85°C
- Humidity: 5-95% non-condensing
- Vibration: 2g @ 10-500Hz
- Shock: 15g peak
- EMC: 10V/m immunity
Package & Shipping
- Includes one 10313/1/1 module
- Mounting hardware included
- Installation guide provided
- 12-month warranty
- Shipping via FedEx, UPS, or DHL
- Express delivery available
- Worldwide shipping support
Frequently Asked Questions
- Q: What is the maximum power capacity?
- A: 4A per Faston pin, 2A per I/O pin
- Q: Does it support redundant systems?
- A: Yes, both redundant and non-redundant
- Q: What is the operating voltage?
- A: 5V DC power distribution
- Q: Can I connect multiple cabinets?
- A: Yes, with additional linking connectors
- Q: What safety approvals does it have?
- A: CE and TÜV certified, UL pending
Compatibility Information
- Works with FSC101 and FSC102 systems
- Compatible with 10315/1/1 backplanes
- Supports 10314/1/1 backplanes
- Integrates with watchdog repeaters
- Works with horizontal bus systems
