Honeywell XNX-AMAV-NHIV1 Industrial Methane Gas Detector

Engineers build the Honeywell XNX-AMAV-NHIV1 transmitter to track volatile methane levels inside dangerous plant locations. This dynamic unit from the Honeywell XNX Universal Transmitter series keeps industrial operators safe from sudden gas leaks. Download the full technical specs in the XNX Universal Transmitter Instruction Manual today.

Key Features and Value Highlights

• Infrared sensor optics deliver precise methane monitoring without interference from ambient weather.
• Painted aluminum enclosure protects internal circuitry from severe chemical erosion and mechanical impacts.
• Local HART communication ports speed up daily routine tests for on-site field technicians.
• Global ATEX and IECEx safety approvals guarantee safe execution in hazardous operating environments.
• Fast internal processors give quick signal feedback to prevent catastrophic industrial plant accidents.

Model Breakdown

• Honeywell XNX Universal Transmitter Series
• └── XNX-AMAV-NHIV1 Specific Part Number Configuration
  • ├── Approval: A (ATEX / IECEx Approved)
  • ├── Entry Type: M (3 x M25 Threaded Entries)
  • ├── Housing Material: A (Painted Aluminum Alloy)
  • ├── Personality: V (m-Volt Sensor Wiring Interface)
  • ├── Option: N (No Relay Options Installed)
  • ├── Local Interface: H (Local HART Port Included)
  • └── Sensor & Range: IV1 (MPD Methane IR Sensor 0-100% LEL)

Complete Technical Parameters

• Brand Name: Honeywell
• Model Code: XNX-AMAV-NHIV1
• Target Gas Type: Methane Gas (CH4)
• Gas Measurement Range: 0-100% LEL (0-5% Volume)
• Sensor Technology Type: Infrared MPD Hydrocarbon Sensor
• Signal Output Range: 4-20mA Signal Output with HART Protocol
• Signal Accuracy Level: ±1% of Full Scale
• Signal Linear Scale: ±0.5% Full Scale Linearity
• Sensor Response Rate: T90 Under 15 Seconds
• Display Sensor Resolution: 1% LEL Increments
• Sensor Sensitivity Drift: Under ±2% LEL Per Year
• Optical Noise Immunity: High Anti-Interference Optical Filters
• Working Power Range: 16 VDC to 32 VDC
• Operating Temperature Limits: -40°C to 65°C (-40°F to 149°F)
• Relative Operating Humidity: 0% to 99% Non-Condensing RH
• Environmental Protection Grade: IP66 Rated Water Dust Seal
• Threaded Conduit Ports: 3 x M25 Cable Entries
• Enclosure Case Material: Heavy-Duty Painted Aluminum Alloy
• Equipment Unit Weight: 6.2 lbs (2.8 kg)

Summary

• The Honeywell XNX-AMAV-NHIV1 gas detection transmitter offers maximum protection against combustible methane leaks.
• Engineers specify this model for its ±1% accuracy and quick 15-second response timing.
• Industrial sites gain stable 4-20mA HART reporting in extreme weather down to -40°C.
• Rugged aluminum housings and solid-state infrared optics ensure long service life in dangerous areas.

Field Installation Instructions

• Fix the aluminum mounting lugs onto a rigid structural beam or flat wall surface.
• Pass external signal wires safely into the chassis through the three M25 threaded entries.
• Seal unused M25 conduit entries with certified flameproof plugs to protect internal circuits.
• Wire the internal terminal block connections correctly according to system engineering wiring diagrams.
• Verify input supply voltage remains within the allowed range before powering up the equipment.
• Calibrate the infrared optics during setup to ensure reliable continuous gas detection performance.

Standard Package Contents

• Original Honeywell XNX-AMAV-NHIV1 transmitter main body unit with HART interface.
• Integrated MPD Infrared Hydrocarbon Sensor Module tuned specifically for Methane detection.
• Custom protective packaging materials designed to shield electronics from severe shock impacts.
• Fast express delivery options available via world carriers like FedEx, UPS, and DHL.

Frequently Asked Questions

• How quickly does the optical IR sensor react to sudden methane leaks?
  • The internal infrared sensor module registers target methane concentrations within fifteen short seconds.
• Can field technicians configure the transmitter without opening the main enclosure?
  • Yes, personnel use the local HART interface port for convenient calibration without breaking seals.
• Does this specific unit measure other flammable gases beside Methane?
  • The pre-installed MPD IV1 sensor option monitors Methane from 0 to 100% LEL range.
• What ambient humidity conditions can this heavy transmitter handle safely?
  • The robust device functions reliably across full humidity ranges from 0 to 99% RH.
• How does the optical sensor resist false alarms in dusty environments?
  • Advanced anti-interference filters eliminate signal noise caused by airborne dust and atmospheric light.
