Summary

The Honeywell brand model XNX-UTSE-NHCB1 serves as a premier universal gas transmitter for industrial safety systems. Plant engineers choose this durable device to monitor combustible gases with high precision. Robust stainless steel housing and local HART capabilities ensure reliable performance in harsh field locations.

Critical Technical Highlights and Core Specifications

Engineers value this transmitter for exact gas detection parameters and sturdy physical attributes.

• Brand and Model Identification
  • Brand: Honeywell
  • Model: XNX-UTSE-NHCB1
  • Product Type: Universal Gas Transmitter
• Performance Parameters
  • Measurement Range: Zero to one hundred percent lower explosive limit for combustible gases
  • Frequency Response: Fast response time under six seconds for rapid hazard alerts
  • Sensitivity: High detection sensitivity for trace gas leaks in large industrial zones
  • Linearity: Exceptional signal linearity across the full operating range
  • Resolution: One percent lower explosive limit display resolution
  • Temperature Range: Operates safely from minus forty degrees Celsius to plus sixty-five degrees Celsius
  • Environment Tolerance: IP66 rated enclosure withstands heavy dust and driving rain
  • Anti-Interference Capability: Advanced internal shielding blocks radio frequency interference
• Hardware and Structural Architecture
  • Approval Rating: UL and CSA certified for hazardous plant locations
  • Cable Entry Type: Three 3/4 inch NPT threaded entries for secure wiring
  • Enclosure Material: Grade 316 stainless steel for maximum corrosion resistance
  • Sensor Personality: Electrochemical and catalytic bead cartridge support interface
  • Installed Options: No auxiliary option modules installed
  • Local HART: Integrated local HART communication port
  • Sensor Type: Catalytic bead sensor for flammable gas detection
  • Physical Weight: Six point eight kilograms

Step-by-Step Installation Guide

Technicians follow precise steps to mount and wire the gas detector safely.

• Mechanical Mounting
  • Bolt the heavy enclosure firmly to a vertical steel pipe or concrete wall.
  • Keep clear space around the sensor head for easy calibration access.
• Electrical Wiring
  • Feed power cables through the 3/4 inch NPT threaded entries.
  • Attach power wires securely to the internal terminal blocks.
  • Ground the metal housing to prevent electrical noise on the loop.

Logistics and Package Contents

Safe shipping methods protect the heavy industrial equipment during transit to your facility.

• Standard Package List
  • One Honeywell XNX-UTSE-NHCB1 transmitter unit
  • Catalytic bead sensor head assembly
  • Factory wiring instruction leaflet
• Shipping Details
  • Fast dispatch via FedEx, UPS, and DHL air cargo carriers.
  • Thick foam padding protects the stainless steel body from damage.

Model Selection and Technical Comparison

Compare this version with alternative part numbers to match your site requirements.

• Comparative Analysis
  • XNX-UTAV-NNCB1: Features an aluminum enclosure instead of 316 stainless steel and uses local HART communication differently.
• Engineering Recommendation
  • Choose the stainless steel XNX-UTSE-NHCB1 model for corrosive offshore platforms or chemical plants.

Frequently Asked Questions

Review expert answers concerning the operation and maintenance of this device.

• What power supply voltage does the unit require?
  • The transmitter operates on standard twenty-four volt direct current industrial power supplies.
• How often must technicians calibrate the catalytic sensor?
  • Operators should test and calibrate the catalytic sensor every six months for best accuracy.
• Can workers replace the sensor head in hazardous zones?
  • Intrinsic safety barriers permit safe sensor head replacement without shutting down plant power.
• What output signals transmit data to the control room?
  • The device sends signals via standard four to twenty milliamp loops and digital HART protocols.
• Does the purchase include a standard factory warranty?
  • Every unit includes a comprehensive twelve-month warranty covering manufacturing defects.

Download the official manual here: XNX Universal Transmitter Manual.
