Honeywell 10100/2/1 Horizontal Bus Driver Module

The Honeywell 10100/2/1 is a high-performance horizontal bus driver module. This reliable component ensures smooth data transmission in industrial control systems. It offers excellent compatibility and meets international safety standards.

Technical Specifications

• Brand: Honeywell
• Model Number: 10100/2/1
• Product Type: Horizontal Bus Driver
• Operating Voltage:5V DC ±5%
• Current Consumption: 35 mA (with A1/A21 cables), 65 mA (with A22 cable)
• Ripple Content: < 50 mV peak-to-peak
• Space Requirements: 4 TE width, 3 HE height (4 HP, 3U)
• Weight: 0.4 kg (0.88 lbs)
• Shipping Weight: 1.5 kg (3.3 lbs)
• Operating Temperature: 0°C to 60°C (32°F to 140°F)
• Storage Temperature: -40°C to 85°C (-40°F to 185°F)
• Relative Humidity: 5% to 95% non-condensing
• Safety Approvals: CE, TÜV, UL
• Vibration Resistance: 5-500 Hz, 2G amplitude
• Shock Resistance: 15G peak, 11ms duration

Package Contents & Shipping

• One Honeywell 10100/2/1 bus driver module
• Installation documentation and user manual
• All necessary mounting hardware included
• Worldwide shipping via FedEx, UPS, and DHL
• Express delivery options available

Frequently Asked Questions

• What systems is this bus driver compatible with?
  The module works with Honeywell control systems using A1, A21, or A22 cables.
• Can I use different cable types simultaneously?
  The module supports one cable type at a time per installation.
• What is the maximum data transmission distance?
  Distance depends on cable type, with A22 supporting longer runs.
• Does this module require special cooling?
  Normal convection cooling is sufficient for standard operation.
• Can I mount this module in any rack position?
  Yes, it fits any standard 19-inch rack location meeting space requirements.
