GE Fanuc IC200PWR101 Power Supply - Dual Voltage 120/240VAC Input

The IC200PWR101 delivers reliable power conversion for industrial systems with dual voltage input (120VAC or 240VAC) and multiple DC outputs.

Key Benefits

• Dual voltage input: Works with 120VAC or 240VAC systems
• Multiple outputs: Provides both 5VDC and 3.3VDC
• Power protection: Built-in short circuit and overload safeguards
• Quick recovery: 20ms holdup time during power dips
• Universal compatibility: 47-63Hz frequency range

Technical Specifications

• Brand: GE Fanuc
• Model: IC200PWR101
• Type: 120/240VAC Power Supply
• Input Voltage: 85-132VAC (jumper in) or 176-264VAC (jumper out)
• Output Voltage: 5VDC (1.5A max) + 3.3VDC (0.25A max)
• Total Power: 27VA maximum
• Frequency: 47-63Hz
• Weight: 1.5kg (3.3 lbs)

Configuration Options

• 120VAC Mode: Install jumper (85-132VAC range)
• 240VAC Mode: Remove jumper (176-264VAC range)

Protection Features

• Automatic short circuit protection
• Overload current limiting
• 20ms holdup time during power loss

Installation Notes

• Verify input voltage before connecting
• Check jumper position for correct voltage range
• Do not exceed 1.5A total output current

Frequently Asked Questions

• Q: Can both outputs be used simultaneously?
  A: Yes, but total current must not exceed 1.5A combined.
• Q: What happens if I forget to set the jumper?
  A: Unit defaults to 240VAC mode - risk of damage if 120VAC input is used.
• Q: Is this power supply fan-cooled?
  A: No, convection cooled design.
• Q: What's the operating temperature range?
  A: 0°C to 60°C (32°F to 140°F) standard.
• Q: Can I parallel multiple units?
  A: No, not designed for parallel operation.

Typical Applications

• PLC system power supplies
• Industrial control cabinets
• Automation equipment power
• Machine tool electronics
