GE Fanuc IC693MDL241 Series 90-30 Input Module: 16-Channel Universal AC/DC Interface

Product Highlights

• Versatile 16-channel input module for both AC/DC signals
• Handles positive/negative logic (0-30VAC/VDC range)
• High 1500V isolation between field and logic circuits
• Individual LED indicators for all 16 channels

Technical Specifications

• Brand: GE Fanuc
• Model: IC693MDL241
• Input Type: AC/DC Positive/Negative Logic
• Voltage Range: 0-30VAC/VDC
• Threshold Levels:
  • ON: 11.5-30V (≥3.2mA)
  • OFF: 0-4V (≤1mA)

Performance Characteristics

• Response Time:
  • 12ms ON (typical)
  • 28ms OFF (max)
• Isolation: 1500V RMS (field to logic)
• Current Draw: 7mA @ rated voltage

Physical Details

• Dimensions: 5.1cm × 12.7cm × 12.7cm (2" × 5" × 5")
• Weight: 0.3kg (11oz)
• Standard Series 90-30 form factor

Installation & Diagnostics

• Single-slot design for space-efficient mounting
• 16 individual LED status indicators
• Tool-free installation in compatible racks

Package & Support

• Includes: IC693MDL241 module
• 12-month manufacturer warranty
• Global shipping via FedEx, UPS, DHL

Industrial Applications

• Machine control status monitoring
• Safety interlock systems
• Conveyor sensor networks
• Equipment presence detection

FAQ

• Q: Can this module handle both AC and DC signals?
  A: Yes, accepts 0-30VAC or VDC input signals
• Q: What's the response time for input changes?
  A: 12ms typical ON, 28ms max OFF response
• Q: Are all inputs individually isolated?
  A: Features 1500V field-to-logic isolation (common group)
