IC693MDL742 GE Fanuc - ESCP Output Module
Manufacturer:
GE
Product No.:
IC693MDL742
Condition:
In Stock
Product Type:
ESCP Output Module
Product Origin:
USA
Weight:
250g
Shipping port:
Xiamen
Warranty:
12 months
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
Brand: GE Fanuc
Model: IC693MDL742
Product Type: 12/24 Volt DC Positive Logic ESCP Output Module
Origin: USA
Specifications:
| Parameter | Details |
|---|---|
| Rated Voltage | 12/24 volts DC |
| Output Voltage Range | 12 to 24 volts DC (+20%, –15%) |
| Outputs per Module | 16 (two groups of eight outputs each) |
| Isolation |
1500 volts between field side and logic side 500 volts between groups |
| Output Current |
1 amp maximum per point 4 amps maximum per group at 50°C 3 amps maximum per group at 60°C |
| Inrush Current | 5.2 amps for 10 ms |
| Output Voltage Drop | 1.2 volts maximum |
| Off-state Leakage | 1 mA maximum |
| On Response Time | 2 ms maximum |
| Off Response Time | 2 ms maximum |
| Power Consumption | 130 mA (all outputs on) from 5-volt bus on backplane |
Features:
- Positive logic design
- Electronic Short Circuit Protection (ESCP)
- LED indicators for output status and short circuit protection
- Two groups with independent protection circuits
Installation:
- Suitable for any I/O slot of a 5 or 10-slot baseplate in a Series 90-30 PLC system
