GE Fanuc IC693MDL931 Output Module - 8-Channel Universal AC/DC

The IC693MDL931 delivers versatile switching capability with 8 isolated outputs that handle both AC and DC voltages for industrial control applications.

Key Features

• Dual voltage support: 5-30VDC or 5-250VAC per channel
• High current capacity: 8A resistive load per output
• Robust isolation: 1500V field-to-logic protection
• Fast switching: 15ms ON/OFF response times
• Energy efficient: Low 45mA/100mA power consumption

Technical Specifications

• Brand: GE Fanuc
• Model: IC693MDL931
• Series: 90-30 PLC
• Outputs: 8 isolated channels
• Voltage Range:
  • DC: 5-30VDC
  • AC: 5-250VAC (50/60Hz)
• Current Rating: 8A resistive per output
• Isolation: 1500V field-to-logic, 500V between groups
• Response Time: 15ms max (ON/OFF)
• Power Consumption: 45mA @5VDC + 100mA @24VDC

Switching Performance

• Minimum Load: 10mA
• Inrush Capacity: 8A for one cycle
• Contact Rating: 8A resistive (derate for inductive loads)
• Frequency Support: 50/60Hz AC

Frequently Asked Questions

• Q: Can I mix AC and DC on different channels?
  A: Yes, each output is independently configurable.
• Q: What's the inductive load rating?
  A: Typically 2A @250VAC for motor loads.
• Q: Are status LEDs provided?
  A: Yes, per-channel output indicators.
• Q: Can outputs be paralleled for higher current?
  A: Not recommended due to synchronization issues.
• Q: What's the expected contact life?
  A> 100,000+ operations at rated load.
