IC695EDS001 DNP3 Outstation Module GE Fanuc
Manufacturer:
GE
Product No.:
IC695EDS001
Condition:
In Stock
Product Type:
DNP3 Outstation Module
Product Origin:
USA
Weight:
2500g
Shipping port:
Xiamen
Warranty:
12 months
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
Overview
The IC695EDS001 is an Ethernet DNP3 Outstation module designed for the GE Fanuc RX3i PacSystem. This module enables communication in DNP3-based industrial control networks, offering enhanced functionality for data management, event handling, and communication topology flexibility.
Technical Specifications
| Parameter | Details |
|---|---|
| Brand | GE Fanuc |
| Series | RX3i PacSystem |
| Part Number | IC695EDS001 |
| Product Type | DNP3 Outstation Module |
| Product Description | Ethernet DNP3 Outstation module |
| Serial Ports | 1 RS232 Station Manager |
| Ethernet Ports | 2 RJ45 Ethernet ports |
| Ethernet Transmission Speed | 10/100 Mbps |
| Maximum DNP3 Masters | 8 |
| Supported Topologies | Line, Star, Daisy chain |
| Ethernet Protocols | LLA, TCP/IP |
| IP Address per Module | 1 |
| MAC Address per Module | 1 |
| Supported Data Points | Up to 12,072 |
| Supported Events | Up to 20,000 |
| Supported Data Objects | DI, DO, CROB, Analog outputs, Time settings, Class polls |
| Maximum Modules per Rack | 4 |
| No. of Modules per RX3i | Up to 4 |
| Power Requirements | 840 mA at 3.3 VDC, 614 mA at 5 VDC |
| Mounting Location | Any I/O slot of RX3i Main Rack |
| Removal and Insertion under Power | Supported |
