GE Fanuc IC697CMM742-LL Ethernet Module: PLC Networking Made Simple

Essential Features

• 10Mbps Ethernet for fast PLC communication
• Multiple connection options: 10BaseT, 10Base2, AUI
• Clear LED status indicators for easy monitoring
• Works with Series 90-70 PLCs

Technical Specifications

• Brand/Model: GE Fanuc IC697CMM742-LL
• Network Speed: 10Mbps (IEEE 802.3)
• Ports:
  • RJ-45 (10BaseT)
  • BNC (10Base2)
  • 15-pin AUI
• Power: 5V DC (2A), 12V DC (0.5A max)
• Temperature Range: 0°C to +55°C

Connection Options

• 4 ways to connect:
  • RJ-45 for standard Ethernet
  • BNC for coaxial cable
  • AUI for external transceivers
  • RS-232 for station management
• Easy setup with status LEDs

Reliability Features

• Replaceable fuse for protection
• Industrial-grade components
• LED indicators for quick diagnostics
• Durable design for factory use

Package & Support

• Includes: Module, user manual
• 12-month warranty
• Fast shipping: FedEx, UPS, DHL

Expert FAQs

• Q: What cables are needed?
  Standard Ethernet or coaxial cables (sold separately)
• Q: Can I use all ports at once?
  No - only one network port can be active
• Q: Is it compatible with 90-30 PLCs?
  No - only for 90-70 series
• Q: What's the maximum distance?
  100m for 10BaseT, 185m for 10Base2
• Q: How to update firmware?
  Via RS-485 software load port
