Technical Specification:

• Memory

  • DRAM: 32 MB of DRAM and is
  • Expandable: up to 64 MB or 96 MB.

• Communications:

  • Serial Communications:
    • Com #1: RS232/RS485
    • Com #2: None
  • Ethernet:
    • LAN #1: 10/100 Mbps
    • LAN #2: None
  • Communication Expansion: Supports GE Fanuc Genius, DeviceNet Slave

• Compact Flash: Includes one Type 2 slot.

• Certifications:

  • Agencies: UL Class 1 Div 2 (Groups A, B, C, D)
  • ATEX: Class 1 Zone 2
  • CE Mark: Complies with CE marking requirements

• Environmental Rating

  • NEMA 4/12/4x, suitable for various environmental conditions.

• Physical Dimensions:

  • Panel Cut-Out: 11.88” x 8.96” x 2.37” (302 mm x 228 mm x 60 mm)
  • Front of Panel & Depth: 13.26” x 10.34” x 0.38” (337 mm x 263 mm x 10 mm)

• Input Voltage

  • 12 VDC @ +/- 20% or 24 VDC @ +/- 20%

• Power Consumption

  • Less than 48W
