IF2B000014 Fixed RFID Reader: High-Performance Industrial UHF Solution

Technical Specifications

• Brand & Model: Honeywell IF2B000014 (IF2 series). Manufacturer: Honeywell. Supplied by Ubest Automation.
• Dimensions & Weight: Length 18.85 cm (7.42 in) or 19.9 cm with splash guard. Width 16.31 cm (6.42 in). Height 4.32 cm (1.70 in). Weight 1.0 kg (2.2 lbs).
• RF Output Power: Adjustable from 1 to 30 dBm in 1 dB steps. Calibrated above 9 dBm for accuracy.
• Antenna Ports: Four RP-TNC connectors support mono-static or bi-static operation. Auto-tuning and fault detection ensure stable performance.
• Connectivity: 10/100 BaseT Ethernet, RS-232, and USB for configuration. Supports PoE (802.3at) or 12 VDC input (30W).
• GPIO: Four inputs (0-40 VDC) and four outputs (0-48 VDC, 0.25A). Powered via PoE or DC input (500 mA at 12 VDC).
• Environmental Ratings: Operating temperature -25°C to 55°C (-13°F to 131°F). Storage from -30°C to 70°C (-22°F to 158°F). Humidity 5% to 95% non-condensing.
• Enclosure: Die-cast magnesium base with a Lexan plastic cover. IP53 rating protects against dust and water spray.
• Protocols & Extensions: Supports LLRP, Honeywell ARX, and Basic Reader Interface (BRI). Includes NXP G2X and Impinj Monza 4QT tag features.
• Management: Built-in web interface, Bonjour, UPnP, and Honeywell SmartSystems client. Supports IPv4, IPv6, DHCP, DNS, NTP, and Syslog.
• Security: FIPS 140-2 compliance for HTTPS, LLRP-secure, and Web Services. RADIUS client and SSL certificate support.
• Optional Expanded Memory: Runs embedded C# .NET or Java apps. Provides 96 MB flash application memory, 96 MB flash data storage, and 64 MB RAM.

Frequently Asked Questions (FAQ)

• Q: Does this reader support high-memory tags like Fujitsu or Tego?
  A: Yes, IF2B000014 works with Fujitsu, Tego, and ATA high memory tags.
• Q: Can I use this reader outdoors?
  A: Yes, the IP53 enclosure resists dust and light rain. Use the splash guard for better protection.
• Q: What shipping carriers do you use?
  A: We ship via FedEx, UPS, or DHL depending on your location.
• Q: Do I need special software to program the reader?
  A: No, you can use the web interface, LLRP, or Honeywell BRI. We also provide an IDL resource kit for Java and C# .NET.
• Q: How do I get technical support for this Honeywell reader?
  A: Contact Ubest Automation directly. Our team knows the IF2B000014 inside out.
