KJ3001X1-BB1 12P0550X142 - Emerson Digital Input Module
Manufacturer:
Emerson
Product No.:
KJ3001X1-BB1
Condition:
In Stock
Product Type:
Digital Input Module
Product Origin:
USA
Weight:
200g
Shipping port:
Xiamen
Warranty:
12 months
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
🔧 Basic Information
| Model | KJ3001X1-BB1 |
| Product Code | 12P0550X142 |
| Product Type | Digital Input Module |
| Manufacturer | Emerson |
📏 Physical Characteristics
| Dimensions | 1.5" x 4.2" x 5.0" (3.8 cm x 10.7 cm x 12.7 cm) |
| Weight | 0 lbs 7.1 oz (0.2 kg) |
| Channels | DI, 8-Channel, 24 VDC, Dry Contact Card |
⚡ Power Specifications
| LocalBus Power Rating | 12 VDC at 100 mA |
| Field Circuit Rating | 24 VDC at 5 mA/channel |
🌿 Environmental Specifications
| Ambient Temperature | 0 to 60°C |
| Shock | 10g ½ Sinewave for 11 msec |
| Vibration | 1mm Peak to Peak from 5 to 16Hz; 0.5g from 16 to 150Hz |
| Airborne Contaminants | ISA-S71.04 –1985 Class G3 |
| Relative Humidity | 5 to 95% Non-Condensing IP 20 |
🔍 Additional Specifications
| Terminal Block Key Position | B1 |
| EMC Compliance | EN 61326-1 |
| MTBF | 150,000 Hours |
| Insulation Resistance | 100 MOhm at 500 VDC |
| Crosstalk | -80 dB |
| Max Line Voltage | 250 VAC |
