GE Fanuc IC200UEX009 Versamax Expansion Unit - PLC Power Booster

Your PLC's Supercharger

• Adds 8 AC inputs + 6 relay outputs to Versamax PLCs
• Handles heavy loads like motors and solenoids
• Universal power works worldwide

Technical Muscle

• Part No: IC200UEX009
• AC Inputs: 8 (120VAC)
• Relay Outputs: 2x10A + 4x2A
• Power: 100-240VAC auto-sensing
• Weight: 1.15 lbs (0.52 kg)
• Response Time: 10ms
• Isolation: 2500VAC input-output
• Temp Range: -25°C to 70°C

Why Engineers Choose This

• ⚡ Dual-power relays - mix 10A & 2A loads
• ⚡ Auto-voltage detection (100-240VAC)
• ⚡ Surge protection up to 4kV
• Status LEDs for every channel
• Vibration-proof (5G rating)

Installation Made Simple

• Snap-on DIN rail clip
• Tool-free terminal blocks
• Clear wiring diagrams
• Hot-swappable design

Package Includes

• IC200UEX009 expansion unit
• DIN rail adapter
• Quick-start card

Order Perks

• 📦 In stock at US warehouse
• ✈️ FedEx/UPS/DHL shipping
• 🔧 12-month warranty

Expert Answers

• Q: Minimum load requirement?
  A: 5mA for inputs, 100mA for outputs
• Q: Water resistance?
  A: IP20 rating - indoor use
• Q: Max wire size?
  A: 12 AWG (3.3mm²)
• Q: Replaceable relays?
  A: Yes - standard sockets
• Q: Lead time?
  A: Ships same business day

🔄 Expand your PLC power - Order by 3PM for same-day shipping!
