Mitsubishi MR-J3-22KB4RJ006 22kW Servo Amplifier

Drive large industrial machines with precision power. The Mitsubishi MR-J3-22KB4RJ006 is a high-performance servo amplifier. It delivers a robust 22 kilowatts of controlled output. This unit is built for demanding 3-phase 400V AC systems. It ensures smooth and accurate motor control for critical applications. Upgrade your automation with reliable Mitsubishi technology.

• High Power Drive: Provides 22 kW output for heavy-duty servo motors.
• Advanced Communication: Fully compatible with high-speed SSCNET III network.
• Precision Control: Uses sine-wave PWM and current control for smooth operation.
• Global Compliance: Meets CE, UL, and RoHS standards for safe use worldwide.

Core Electrical Specifications

• Brand & Model: Mitsubishi MR-J3-22KB4RJ006 Servo Amplifier.
• Power Supply: 400 VAC, 3-phase input voltage.
• Rated Output: 22 kilowatts (kW) continuous power.
• Control Method: Sine-wave PWM and current control.
• Communication: Integrated SSCNET III high-speed fiber optic interface.
• Standards Compliance: Certified for CE, UL, and RoHS.

Physical & Environmental Ratings

• Protection Class: IP00 (Open Frame). Requires installation in a protective enclosure.
• Operating Temperature: Functions from 0°C to 55°C.
• Storage Temperature: Suitable for storage from -20°C to 65°C.
• Cooling Method: Forced air cooling with internal fan.
• Mounting: Designed for vertical mounting on a panel or heatsink.

System Integration & Compatibility

• Motor Compatibility: Designed to drive Mitsubishi MELSERVO servo motors.
• Network Integration: Connects directly to SSCNET III master controllers (e.g., Q Series PLCs).
• Input Power Requirements: Requires a stable 3-phase 400V AC (±10%) power source.
• Regenerative Braking: Supports connection to an external regenerative brake resistor (sold separately).
• Safety Features: Includes overcurrent, overload, and overvoltage protection circuits.

Packaging & Warranty

• The Mitsubishi MR-J3-22KB4RJ006 is supplied new in original factory packaging.
• Includes the amplifier unit and installation manual.
• This product is covered by a 12-month warranty against manufacturing defects.
• We ship globally via express courier: FedEx, UPS, and DHL.
• You will receive tracking details immediately after your order is processed.

Frequently Asked Questions

What size cabinet and cooling are needed for this IP00 amplifier?

• Install the MR-J3-22KB4RJ006 in a well-ventilated industrial cabinet rated at least IP54. You must provide adequate airflow around the unit, following the clearance dimensions in the manual, to prevent overheating due to its high power output.

Can I connect multiple motors to this single amplifier?

• No, this is a single-axis amplifier. It is designed to control one three-phase servo motor. For multi-axis systems, you need one amplifier per motor, all networked via SSCNET III.

How do I select the correct external regenerative resistor?

• The resistor selection depends on your motor's inertia and the braking cycle. Consult the amplifier's technical manual or Mitsubishi's sizing software. Using an undersized resistor will cause amplifier faults during deceleration.

Is this amplifier compatible with older MR-J2 series motors?

• While electrically possible, it is not recommended. For optimal performance and access to all features, pair the MR-J3-22KB4RJ006 with a compatible MR-J3 or later series servo motor. Always check the motor-amplifier combination list.

What is the advantage of SSCNET III over analog/pulse control?

• SSCNET III uses a digital, noise-immune fiber optic link. It allows for faster command updates, synchronous multi-axis control, and simplified wiring with fewer connections compared to traditional analog or pulse train interfaces.
