Mitsubishi MR-J3-500BS-EB - 5 kW Industrial AC Servo Drive

Power your heavy-duty automation with the Mitsubishi MR-J3-500BS-EB. This high-performance 5 kW AC servo amplifier delivers reliable motion control for demanding applications like large presses, extruders, and material handling systems. Operating on three-phase 200V AC power, it features the high-speed SSCNET III network for precise control and includes protective conformal coating for durability in industrial environments.

Why Choose This Drive?

• High Power Output: Provides a solid 5 kW (approximately 6.7 HP) of driving force for medium-to-large machinery.
• Robust Industrial Design: Conformal coating protects internal circuits from dust, moisture, and chemical contaminants for longer life.
• Fast Network Integration: SSCNET III fiber-optic communication ensures quick, noise-free data exchange with your motion controller.
• Certified Safety: Complies with Safety Category B standards, contributing to safer machine designs.

Complete Technical Specifications

Brand & Series: Mitsubishi Electric MELSERVO MR-J3 Series

Full Model Number: MR-J3-500BS-EB

Product Type: AC Servo Amplifier (Drive)

Rated Output Power: 5 kW

Supply Voltage: 3-Phase, 200 VAC, 50/60 Hz

Communication Interface: SSCNET III (High-Speed Serial Network)

Protection Coating: Conformal Coating Applied (for environmental resistance)

Safety Standard: Complies with Safety Category B

Cooling Method: Forced Air Cooling (typical for this power range)

Enclosure Rating: IP00 (Open Chassis - requires cabinet installation)

Ambient Temperature: 0°C to +55°C (Operating), -20°C to +65°C (Storage)

Regenerative Braking: Requires external regenerative resistor (sold separately).

Compatible Motors: Mitsubishi HC-SF52 to HC-SF152, HC-RF103 to HC-RF153 series and other 5kW rated MELSERVO-J3 motors.

Installation & Compatibility Guide

Install the MR-J3-500BS-EB inside a protective control cabinet. Connect a three-phase 200V AC power source with proper disconnects and fusing. Link the drive to your motion controller (e.g., Mitsubishi Q series CPU) using an SSCNET III optical cable. Connect a compatible 5 kW servo motor. You will likely need to purchase and connect an external regenerative resistor to handle braking energy. Ensure adequate cabinet ventilation for the drive's cooling fan.

Package & Warranty

What's Included: 1 x Mitsubishi MR-J3-500BS-EB Servo Drive Unit.

Our Guarantee: This industrial product is backed by a full 12-month warranty.

Fast Shipping Options

We deliver worldwide using reliable carriers: FedEx, UPS, and DHL.

Frequently Asked Questions (FAQ)

What is the main difference between SSCNET III and SSCNET III/H?

SSCNET III is the standard high-speed network. SSCNET III/H is an enhanced version with even higher transmission speeds. The MR-J3-500BS-EB uses SSCNET III, which is fully compatible with controllers supporting this protocol.

What does "conformal coating" do?

It is a thin protective polymer film applied to the circuit board. It shields electronic components from corrosion caused by humidity, dust, and mild chemical exposure, increasing reliability in non-hermetic industrial environments.

Is a braking resistor included?

No. A drive of this power (5 kW) typically requires an external regenerative braking resistor to be purchased separately and connected to the designated terminals to dissipate energy during motor deceleration.

Can I use this drive in a single-phase power system?

No. The MR-J3-500BS-EB is specifically designed for three-phase 200V AC input. Using single-phase power will not work and could damage the unit.

What does Safety Category B mean?

It is a defined level of safety for control systems. Category B signifies the drive incorporates basic safety principles and fault detection. For full machine safety, it must be integrated into a wider safety circuit designed by the machine builder.
