MTL Instruments | Isolating Driver MTL4546Y
Manufacturer:
MTL
Product No.:
MTL4546Y
Condition:
In Stock
Product Type:
Isolating Driver
Product Origin:
USA
Weight:
500g
Shipping port:
Xiamen
Warranty:
12 months
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
⚡ Product Overview
| Manufacturer | MTL Instruments |
| Product No | MTL4546Y |
| Product Type | Isolating Driver |
| Number of Channels | One |
🔧 Electrical Specifications
| Working Range | 4 to 20mA |
| Digital Signal Bandwidth | 500Hz to 10kHz |
| Maximum Load Resistance | 800Ω (16V at 20mA) |
| Minimum Load Resistance | 90Ω (Short-circuit detection at < 50Ω) |
📦 Physical Characteristics
| Weight | 0.5 Kg |
| Dimensions | Standard module size |
⚙️ Performance Details
| Transfer Accuracy at 20°C | Better than 20µA |
| Temperature Drift | < 1.0µA/°C |
| Input & Output Circuit Ripple | < 40µA peak-to-peak |
| Response Time | Settles within 200µA of final value within 100ms |
💡 Key Features
| Communications Supported | HART |
| LED Indicator | Green: power indication |
| Under/Over Range Capability | Under range = 1mA, Over range = 24mA (Load ≤ 520Ω) |
| Input Characteristics | Normal < 6.0V, Open-circuit < 0.9mA, Short-circuit < 0.9mA |
🔍 Safety & Power Information
| Maximum Current Consumption | 35mA at 24V DC (with 20mA signals into 250Ω load) |
| Power Dissipation | 0.8W at 24V |
| Safety Description | Uo=28V Io=93mA Po=651mW Um = 253V rms or dc |
📊 Additional Specifications
| Operating Temperature | -20°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Humidity Range | 5% to 95% (non-condensing) |
| Certification Standards | ATEX, IECEx certified |
