Home » MVI69-ADM Programmable Application Development Module
ProSoft

MVI69-ADM Programmable Application Development Module

In stock
Manufacturer:
ProSoft
Product No.:
MVI69-ADM
Condition:
In Stock
Product Type:
Programmable Application Development Module
Product Origin:
USA
Weight:
630g
Shipping port:
Xiamen
Warranty:
12 months

UBEST – Trusted Global Automation Parts Supplier

We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.

About Us | Contact

🔧 Technical Specifications

Feature Details
📦 Module Type
  • Standard 1769 single-slot module
⚡ Power Supply Rating
  • Current Load: 800 mA max @ 5 VDC
  • Power Supply Distance Rating: 2 (L43 and L45 installations)
  • Applicable to first 2 slots on the 1769 bus
🌡 Operating Temperature
  • 0°C to 60°C (32°F to 140°F)
❄️ Storage Temperature
  • -40°C to 85°C (-40°F to 185°F)
💧 Relative Humidity
  • 5% to 95%, non-condensing
🔗 Serial Ports
  • 3 ports, electrically isolated
  • RJ45 to DB-9M cables included
  • RS-232 supported only on CFG port
  • No hardware handshaking
🌐 Ethernet Specifications
  • 10/100 Base-T Ethernet compatible
  • Broadcast Storm Resiliency: ≤ 5000 ARP frames/second for up to 5 minutes
  • Electrical Isolation: 1500 Vrms
💡 LED Indicators
  • Power and Module Status
  • Application Status
  • Configuration (CFG) Port Activity
  • Ethernet Port Activity
  • Error Status
📦 Shipped Accessories
  • Includes RJ45 to DB-9M cables for all ports
  • 6-foot RS-232 configuration cable
